Bayco Products, Inc. • 640 South Sanden Blvd. • Wylie, TX 75098 • 1-800-233-2155 • 1-469-326-9400 • www.nightstick.com

INS-9854XL-18b

Instruction Manual

NSR-9854XL

US PATENT 9,713,217 AND 10,088,138

THANK YOU FOR SELECTING THE NIGHTSTICK NSR-9854XL!

PLEASE SAVE THESE INSTRUCTIONS

Please read these instructions before using your 9854XL. They include important

safety and operation information. Be sure to charge the 9854XL fully before the  rst

use. A battery is fully charged when the charger light is green.

Included in the box - Compris dans la boîte - Incluido en la caja

WARNINGS

yLithium-ion batteries must be used and charged properly. Improper use can

result in serious injury,  re, or death.

yNOT FOR USE IN HAZARDOUS LOCATIONS. Do not use this product in

explosive atmospheres, near  ammable liquids, or where explosion proof or

intrinsically safe lighting is required.

yDO NOT use this product in the proximity of vehicles or equipment when there

is a risk of  ammable liquids coming into contact with the  ashlight.

yLight can become hot while on. To prevent damage DO NOT cover or place

next to any potentially  ammable materials while in use.

yDo not leave the battery in direct sunlight or use or store the battery inside cars

in hot weather.

yDo not expose the battery to water or salt water, or allow the battery to get wet.

yDo not store the battery with metallic objects that may cause a short circuit.

yImmediately discontinue use of the battery if the battery emits an unusual

smell, feels hot, changes color, changes shape or appears abnormal in any way.

yKeep out of the reach of children.

INITIAL USE

yFully charge the 9854XL before the  rst use, or if the battery is new or has been

unused for several months. The maximum charge time required is approximately

6 hours.

DAILY USE

yUse only the supplied Nightstick USB cable and battery. For best performance,

charge the 9854XL when the  ashlight beam starts to dim.

yConnect the USB cable into a power adapter.

yWith the  ashlight facing upward, remove the rubber USB port cover, and plug

the micro USB into the  ashlights micro USB port.

yThe LED indicator changes to constant red indicating the 9854XL is properly

inserted into the charger and is in fact charging. The LED indicator remains red

until the battery is fully charged. At full charge, the LED indicator turns green.

yThe total time to full charge the 9854XL varies depending on the remaining

charge in the battery pack.

CR-123 BATTERY CARRIER

The CR123 battery carrier converts the 9854XL from rechargeable Lithium-ion

to non-rechargeable Lithium battery operation.

Load two CR-123 Lithium batteries with the positive terminals pointing in the

direction of the arrow. NOTE: The  ashlight cannot be charged with the CR-123

CARRIER installed.

OPERATION

The 9854XL has seven light modes: momentary  ashlight, full

brightness  ashlight, medium brightness  ashlight, low brightness

 ashlight,  oodlight, dual-light and strobe. The 9854XL has a unique tail-

switch that operates both the  ashlight and  oodlight in one con guration.

Momentary Flashlight Mode

Lightly press the upper raised portion of the tail switch (without clicking the

 ashlight on) for momentary operation. Release the switch to turn the light off.

Constant-on

Fully press the upper raised portion of the tail switch until it clicks and then

release for constant-on in high-brightness mode. Press and release the switch to

turn the light off.

Select Brightness Level

Press and hold down the upper raised portion of the tail switch. The light will

cycle from high to medium to low and then back up again at a rate of approximately

one mode per second. The light will continue to cycle up and down through the

various modes as long as the switch is held down. When the desired brightness

level is reached, simply release the switch, and the light will remain in that

brightness mode. Press and release the switch to turn the light off.

Floodlight

Press the bottom recessed portion of the tail switch until it clicks and then

release for  oodlight mode. Press and release the switch again to turn the light off.
