Instruction Manual

TWM-350/850XL/850XLS

US PATENT 9,713,217 & 10,451,384

PACKAGE CONTENTS

y1 - Weapon Mounted Light

y2 - CR123A Lithium Batteries

y3 - Inserts P1, P2, and P3 (P2 is pre-installed)

y2 - Cross Rail Mounting Cap Head Screws (1 pre-

installed & 1 spare)

y1 - Allen Wrench

WEAPON SAFETY

PLEASE BE SURE TO READ, UNDERSTAND AND FOLLOW

THESE SAFETY AND OPERATING INSTRUCTIONS WHEN

HANDLING A FIREARM OR THE NIGHTSTICK TWM WHEN

MOUNTED ON A FIREARM. FAILURE TO DO SO CAN BE

DANGEROUS AND COULD RESULT IN SERIOUS INJURY,

DAMAGE TO PROPERTY, OR DEATH.

Use of a rearm under any circumstance is inherently

dangerous. SERIOUS INJURY OR EVEN DEATH may

result without proper training in the safe handling of rearms.

Proper training should be obtained from an accredited

rearms safety program conducted by a qualied instructor.

Read, understand and follow all of the safety instructions

that came with your rearm before attaching your new TWM.

yAlways assume every rearm is loaded and treat that

rearm as such.

yNever point a rearm at anything that you are not willing

to destroy.

yNever service your rearm or your TWM when mounted

on a rearm without rst activating the weapon’s safety (if

applicable), removing the magazine, opening the action

and physically and visually inspecting to make sure that no

ammunition is installed in the rearm.

WEAPON MOUNTED LIGHT SAFETY

yNightstick recommends that the TWM should only be

activated with the non-trigger hand (support hand) while

employing a two-hand grip on the rearm and with the

trigger nger fully outside the trigger guard when applicable.

WARNING: FAILURE TO DO SO COULD RESULT IN

AN ACCIDENTAL DISCHARGE AND SERIOUS INJURY,

DAMAGE TO PROPERTY, OR DEATH.

yThoroughly practice (employing safe training conditions) with

the TWM and an unloaded rearm before using the weapon.

BEFORE ATTACHING, INSPECTING OR

SERVICING THE TWM

yEngage the safety on the rearm (if applicable).

yRemove the magazine from the rearm (if applicable).

yOpen the action and visually and physically inspect the

chamber to be sure it is empty.

yKeep the barrel pointed in a safe direction at all times and

never place your hand in front of the muzzle.

WARNING: IT IS IMPERATIVE THAT SAFETY

MEASURES BE EMPLOYED AT ALL TIMES WHILE

HANDLING A FIREARM.

GENERAL SAFETY WARNINGS

yNOT FOR USE ABOVE HAZARDOUS LOCATIONS

yDO NOT use in explosive atmospheres, near ammable

liquids, or where explosion proof lamps are required.

yDO NOT use in the proximity of vehicles or equipment

when there is a risk of ammable liquids coming into

contact with the ashlight.

yDO NOT expose the batteries to water or salt water, or

allow the batteries to get wet.

yDO NOT store the batteries with metallic objects that

may cause a short circuit.

yImmediately discontinue use of the batteries if they emit

an unusual smell, feel hot, change color, change shape or

appear abnormal in any way.

yKeep out of the reach of children.

STEP 1. INSTALL THE BATTERIES

Image 1Image 2Image 3

yTo install the included CR123A Lithium Batteries in

the TWM, begin by unscrewing the screw on the battery

compartment door. (Image 1) This screw is designed to

remain in the battery compartment door once it has been

unscrewed, do not attempt to remove it.

yInsert both batteries into the battery compartment paying

attention to the battery orientation marking on the sides of the

light near the battery compartment door. (Image 2)

yRe-install the battery compartment screw by pressing the

door fully closed and then tightening the screw until it is

hand tight. Do not over tighten. (Image 3)

yTest the operation of the light (see OPERATION below).

STEP 2. INSTALL THE LIGHT ONTO FIREARM

The TWM is designed to be easily attached and

detached from the rearm’s tactical rail. The rearm must

have a tactical rail and it must have at least one cross rail

slot. The TWM is not designed to be used on a rearm that

does not have a cross rail slot.

IMPORTANT: The TWM comes pre-congured with the

P2 Modular Channel-locking insert that ts Glocks and

most handgun models. If the t is not correct for your

specic handgun, use the Allen wrench to switch to the

P1 or P3 insert that works best for your rearm.

Refer to the TWM-Series Modular Insert Reference Guide

for a list of handgun models and inserts.

Image 4Image 5Image 6

yPush inward on the head of the rail clamp tension

thumbscrew to open the adjustable portion of the rail clamp.

(Image 4)

yWhile making sure your rearm is in a safe condition and

the barrel is pointed in a safe direction, place the xed portion

of the rail clamp into the groove of the tactical rail on your

rearm and align the insert tab with the slot on your rearm.

yRotate the light onto the tactical rail (Image 5). Release the

pressure on the tension thumbscrew making sure that the light

is gripping both sides of the tactical rail of the rearm. Verify that

the insert tab is fully seated into the rail slot. (Image 6)

Image 7Image 8

yWhile holding the light tightly to the tactical rail of the rearm,

tighten the rail clamp tension thumbscrew by hand. (Image 7)

yUse a large coin (a quarter works well) to fully tighten the

tension thumbscrew. (Image 8)

WARNING: NIGHTSTICK STRONGLY RECOMMENDS

PERIODICALLY CHECKING TO INSURE THAT THE ALLEN

SCREW AND THE RAIL CLAMP TENSION THUMBSCREW

REMAIN TIGHT. FAILURE TO KEEP THESE TIGHT CAN

RESULT IN DAMAGE TO THE TWM AND/OR THE CROSS

RAIL INSERTS UNDER CONTINUOUS RECOIL.

SCAN FOR MOUNTING

INSTRUCTION VIDEO

https://youtu.be/mI0GE_qKFi8

STEP 3: TEST FUNCTION OF THE SWITCHES

yVerify that both switches have a full range of movement

and that the TWM is operating properly.

yThe TWM is now properly installed on your rearm.

OPERATION

Left Down-Momentary OnRight Down-Momentary OnNeutral Off

Left Up-Constant OnRight Up-Constant OnNeutral Off

yThe TWM uses Dual Dependent Locking Switches.

yEach switch has 3 positions of operation: Neutral

- Off, Down - Momentary-on and/or Strobe (model

dependent),Up - Constant-on

yIn order to operate one of the switches, the switch on the

opposite side must be in the Neutral Position (off).

MOMENTARY-ON MODE

Press down and hold either the left side switch or the right

side switch to activate the momentary-on mode. Release the

switch, back to the Neutral position and the light turns off.

NOTE:While in Momentary-on Mode on one side of the

TWM, the Dual Dependent Locking Switch design of the TWM

prevents the switch that is NOT in use from accidentally moving

out of the Neutral position. This eliminates the possibility of an

unintended activation of the light (i.e. while the left side switch

is being held in the Momentary-on Mode, the right side switch

is mechanically locked in the Neutral position).

CONSTANT-ON MODE

Press up, click and release either the left side switch or

the right side switch to activate the constant-on mode. From

the constant-on mode slightly press the switch downward into

the Neutral position to turn the light off.

STROBE MODE (350S/850XLS Models Only)

To activate (using either switch), quickly press down

twice and hold on the second press. This will activate the

strobe. The strobe mode will continue until the switch is

released back to the Neutral position.

STROBE WARNING

Exposure to strobing lights may cause dizziness,

disorientation, and nausea. A very small percentage of people

suffer from photosensitive epilepsy and may experience

seizures or blackouts triggered by strobing lights. For more

information from the EPILEPSY FOUNDATION about

photosensitivity and seizures, please visit www.epilepsy.

com. Anyone who has had symptoms linked to this condition

should consult a doctor before using this product.

WARRANTY

LIMITED LIFETIME WARRANTY

Bayco Products, Inc. warrants this product to be free

from defects in workmanship and materials for the original

purchaser’s lifetime. The Limited Lifetime Warranty includes

the LEDs, housing and lenses. Rechargeable batteries,

chargers, switches, electronics and included accessories are

warranted for a period of two years with proof of purchase.

Normal wear and failures which are caused by accidents,

misuse, abuse, faulty installation and lightning damage are

excluded.

We will repair or replace this product should we determine

it to be defective. This is the only warranty, expressed or

implied, including any warranty of merchantability or tness

for a particular purpose.

For a complete copy of the warranty, go to www.

baycoproducts.com/nightstick-product-support/warranties.

Retain your receipt for proof of purchase.
