TREVOCE SUBWOOFER INSTALL GUIDE EQ SEIRES

TREVOCE TREVOCE15 EQ 12 EQ

TREVOCE EQ SERIES SUBWOOFER INSTALL GUIDE

Installation Precautions:

Before installing

Thank you for buying the latest version of our most popular subwoofer.

The additional upgrades we have made make this the best all-round sub in our history. Incorporated in the Trevoce EQ Series is the new

native EQ. The native EQ has allowed us to extract the maximum bass extension possible from our design. This allows the full range of

musical instruments and special effects to be reproduced. The Trevoce EQ Series does this all without any increase in the size of the

sub. Our Trevoce subs offer the smallest footprint you will nd in triple driver designs.

Before connecting your subwoofer, make sure all equipment is switched off and that voltage switch is set to your country’s voltage. Do

not connect the subwoofer power supply cable before completing all connections.

Features:

World Class Digital Amplier Technology

The TreVoce Series powered subwoofer incorporates the latest digital amplier technology to maximize performance

while generating very little heat. In standby mode, the unit consumes less than 0.5 watts, making it one of the greenest

solutions available.

Tuned System Performance

Rear mounted volume control, low pass crossover, phase control ensure optimal system integration and built-in native EQ

ensures the deepest bass frequencies.

Cabinet

An attractive furniture quality solid cabinet with ‘leather’ nish, provides the foundation for high sound quality and clarity.

Connection & Controls

1. High Level Inputs

Use for Left/Right connection from speakers.

2. Line Level Input

Use for Left/Right connection from subwoofer-out,

or line-out, on amp/AVR.

3. LFE Input

Connect to the LFE output on the Receiver/Processor.

4. Balanced XLR Input

For lower noise connection if available.

5. Power LED

(Red) Standby Mode - (Blue) Power Mode ON

6. Power Mode Switch

Set the power mode ( OFF, AUTO, or ON )

7. Phase Switch

Allows you to set the phase of the woofer 0-180°

8. Crossover Control

Adjusts the subwoofers frequency output output to match

main speakers

9. Volume Control

Adjusts subwoofer volume level.

10. Voltage Switch

Select input voltage. Default: 110-120V or 220-240V

11. Master Power Switch

Controls the main power to the subwoofer

12. AC Power Cord

Connect the included AC power cord.

13. Fuse Holder

Master Power Fuse. Includes spare fuse inside holder.

TreVoce EQ Series Manual 2/24

Optimal Speaker Design | Brea, CA | osdaudio.com

Specications

Warranty Information

Spec TreVoce15 EQ TreVoce12 EQ

Power 1000W RMS 2000W Peak 375W RMS 750W Peak

Active Woofer 15” 12” Graphite Paper Cone Graphite Paper Cone

Passive Woofer Dual 15” Glass Fiber Cone Dual 12” Glass Fiber Cone

Frequency

16 -160 Hz 3dB 18 -160 Hz 3dB± ±

Phase 0-180° 0-180°

Voltage 100-120V AC / 220-240V AC 100-120V AC / 220-240V AC

Inputs Hi Level / Low Level / LFE Hi Level / Low Level / LFE

Dimensions (WxHxD) 19.3 x 19.3 x 19.3 in (WxHxD) 16 x 15.4 x 15 in

Weight 98 lbs 46 lbs

All Optimal Speaker Design powered subwoofer products have a 2 Year Limited Warranty against defects in materials and workmanship. Proof of purchase must accompany

all claims. During the warranty period Optimal Speaker Design will replace any defective part and correct any defect in workmanship without charge for either parts or labor

Optimal Speaker Design may replace returned speakers with a product of equal value and performance. In such cases, some modication to the mounting may be necessary

and are not Optimal Speaker Designs responsibility.

For this warranty to apply, the unit must be installed and used according to its written instructions. If necessary, repairs must be performed by Optimal Speaker Design. The

unit must be returned to Optimal Speaker Design at the owner’s expense and with prior written permission. Accidental damage and shipping damage are not considered

defects, nor is damaged resulting from abuse or from servicing performed by an agency or person not specically authorized in writing by Optimal Speaker Design

Optimal Speaker Design sells products only through authorized dealers and distributors to ensure that customers obtain proper support and service. Any Optimal Speaker

Design product purchased from an unauthorized dealer or other source, including retailers, mail over dealers and on-line sellers will not be honored or serviced under existing

Optimal Speaker Design warranty policy. Any sale of product by an unauthorized source or other manner not authorized by Optimal Speaker Design shall void the warranty on

the applicable product.

Damage to or destruction of components due to application of excessive power voids the warranty on those parts. In these cases, repairs will be made on the basis of the

retail value of the parts and labor. To return for repairs, you must email customer service at RMA@audiogeargroup.com for a Returned Merchandise Authorization (RMA)

number# then the unit must be shipped to Optimal Speaker Design at the owner’s expense, along with a note explaining the nature of service required. Be sure to pack the

speaker(s) in a corrugated container with at least 3 inches of resilient material to protect the unit from damage in transit.

This Warranty Does Not Cover: Damage caused by abuse, accident, misuse, negligence, or improper operation (installation) • Any products that have been altered or modied

• Any product whose identifying number of decal, serial #, etc. has been altered, defaced or removed • Normal wear and maintenance.

TREVOCE EQ SERIES SUBWOOFER INSTALL GUIDE

2. Set the controls and switches to their initial setup positions:

VOLUME set the dial to 50% or 12 o’clock

CROSSOVER adjust the upper frequency limit. The purpose is to control the overlap the upper frequencies of the

subwoofer and the main speakers lower frequencies. Check your main speakers specs to determine their low-end limit.

PHASE set to 0°

3. Play a movie scene or soundtrack and set the system volume to an average level. Listen to the bass level from your

favorite listening position and adjust the volume accordingly.

4. Continue listening to your favorite source track and experiment with the phase control until you nd the best setting

for you. Depending on the location of the subwoofer the bass may sound louder and deeper when the phase has been

optimized. In some cases adjusting the phase will have no audible difference.
