VeriSafe

™

2.0 Absence of Voltage Tester (AVT)

Instruction Manual

Lit. No.: B21110

Date: 10/06/2022 Revision: 4 [English]

Model No(s):VS2-AVT Series

Table of Contents

NOTE:In the interest of higher quality and value, Panduit

™

products are continually being improved and updated. Consequently, pic-

tures may vary from the enclosed product.

NOTE:Updates to this Instruction Manual may be available. Check www.panduit.com for the latest version of this manual.

TO REDUCE THE RISK OF INJURY, USER MUST READ INSTRUCTION MANUAL

TM

For a copy of Panduit product warranties, log on to www.panduit.com/warranty

For more information

Visit us at www.panduit.com/verisafe

1002985, B21110_EN_rev4

North America Tech Support:

[email protected]

Tel: 866.405.6654

EU Tech Support :

[email protected]

Tel: 31.546.580.452

Fax: 31.546.580.441

Asia Pacific Tech Support:

[email protected]

Tel:

Singapore: 1-800-Panduit (7263848)

Australia: 1-800-Panduit (7263848)

Korea: 02.21827300

Tech Support

Hazardous Locations .................................2

Safety Information ...................................3

Informations relatives à la sécurité ......................4

System Configuration ...............................5, 6

Components ......................................5

Part Number Identification ...........................5

Power for AVT Test .................................5

DC Power Input ....................................5

Indicator Module ...................................6

Absence of Voltage Outputs ..........................6

Technical Specifications .............................7, 8

Environmental Ratings, Applications ....................7

AVT Power Requirements .............................7

AVT Quiescent Current, Voltage Illumination Level ..........7

Functional Safety ...................................8

Standards and Certifications ..........................8

Dimensions .........................................9

Schematics .....................................10, 11

3-Phase Delta, 3-Phase Wye .........................10

Single Phase .....................................10

DC .............................................11

Installation Considerations ...........................12

General Information ................................12

Effect on SCCR ...................................12

Use of Overcurrent Protection ........................12

Installation Instructions ...........................13, 14

Commisioning Checklist ..............................15

Operating Instructions ...............................16

Troubleshooting ....................................17

Maintenance ....................................18, 19

Warranty ..........................................20

The VeriSafe

™

2.0 Absence of Voltage Tester (AVT) is a permanently-mounted tester that is used to verify a circuit is de-energized prior

to opening an electrical enclosure. Once installed, a push of a button enables personnel who have been trained on the operation of the

tester to verify the absence of voltage and see an active indication when the absence of voltage is confirmed.

The VeriSafe

™

2.0 AVT safety function tests for absence of voltage. When the voltage is verified below 3VAC and 3VDC, the green

absence of voltage indicator illuminates and the external outputs activate for 5 seconds.
