Instruction Manual

SEnsor

2PowerBox-Systems − World Leaders in RC Power Supply Systems

Dear customer,

congratulations on your decision to purchase the from PowerBox Sensor V3

our range. We wish you many hours of pleasure and success with the PowerBox

Sensor V3!

PRODUCT DESCRIPTION

The PowerBox Sensor V3 is the third generation of the , which PowerBox Sensor

is well-known throughout the world. For almost twenty years the PowerBox

Sensor has represented the standard for small to medium-sized models thanks to

its compact format and versatility.

By using the latest components we have been able to reduce the size of the Sensor

V3 signicantly. For example, the case is now exactly half as deep (11 mm compa-

red with 22 mm). Nevertheless, the Sensor V3 still ts neatly in the aperture used

by its predecessor.

The introduction of a top-quality aluminium case, machined and anodised, has

brought a substantial increase in the unit’s cooling efciency, with the result that

the maximum continuous current capacity of the PowerBox Sensor V3 is around

35 % higher. In fact, the peak load capacity is twice as high: the can Sensor V3

handle more than 20 A for several seconds!

The Sensor V3 offers two user-selectable output voltages: for normal servos it can

be set to a regulated 6.0 V, while a regulated 7.8 V is available for HV servos– pro-

vided that the batteries supply the higher input voltage required.

www.powerbox-systems.com 3

Power to the unit can be drawn from four different battery types: LiPo, LiIon, LiFePo,

NiMH. Ultra-bright RGB LEDs are tted to indicate battery voltage; they light up in

various colours to display the charge status of the batteries.

CORE users also benet from one special additional feature: both battery voltages

can be displayed directly on the transmitter by means of telemetry.

FEATURES

+ High-performance battery backer

+ Ultra-light unit, compact format

+ Double regulated output voltage

+ Redundant switch and regulator circuitry

+ User-selectable output voltage: 6.0 V or 7.8 V

+ Separate RGB LED voltage indicators for each battery

+ Telemetry support for systemsCORE

+ Supports 4 different battery types: 2s LiPo, 2s LiIon, 2s LiFePo and 5s NiMH

+ Regulator monitoring

+ Suppression of servo feedback currents

Produktspezifikationen

Marke:	PowerBox Systems
Kategorie:	ferngesteuertes Spielzeug
Modell:	Sensor V3
Breite:	65 mm
Tiefe:	26 mm
Produktfarbe:	Grau
Höhe:	11 mm
Eingebautes Display:	Nein
Typ:	Radio-Controlled (RC) Model Accessories & Supplies
Menge pro Packung:	1 Stück(e)
Batterien erforderlich:	Ja
