Seite 1/6
What s In The Box’
Please inspect the contents of your shipped package to ensure you have received everything that
is listed below.
All rights reserved.
No part of this document may be reproduced, stored in a retrieval system, or transmied by any form or by any means,
electronic, mechanical, photo copying, recording, or otherwise, except as may be expressly permied by the applicable copyright -
statutes or in wring by the Publisher.
Tango 360° Camera Rotang Dutch Angle Rig (P TNGO- -01)
A s s e m b l y M a n u a l
Camera Plaorm
Tango 360° Camera Rotang Dutch Angle Rig
Camera Plaorm Rods with Stopper
1.5mm L
Type Allen Key
2
Loosen and remove the stopper of the camera
plaorm rods, as shown in the picture.
Loosen and remove the stoppers from the
camera plaorm rods, as shown in the
picture.
Tango 360° Rig Setup
Insert the rods into the camera plaorm and
then secure them properly using a 1.5mm
Allen key. Follow the same process on the
other side as well.
Loosen the red knob of the Tango 360°
camera rotang Dutch angle rig and then
insert it into the rods.
Follow the same process on other side.
Aer inserng the rods into the camera
plaorm hole, insert the stoppers from the
boom and ghten them to secure properly.
3
Aer inserng it into the rods, secure it
properly with the help of the red knob and
then secure the rods properly from the top
with the help of stoppers.
Properly aach the Ball Head (Not Included)
to the tripod, by matching it with the 3/8”
thread of the Tripod.
NOTE: Tripod comes with a (1/4” & 3/8”) quick
tripod mounng threads.
Remove the camera plate as shown.
Camera Setup
To give the Ball Head a 360° rotaon, loosen
the knob a lile and then rotate the knob to
ghten it again. To remove the Camera Plate,
loosen the knob.
Aach the camera plate to the boom
mounng thread of tango dutch angle rig 1/4”
and secure it with the help of an Allen key.
Rods are properly secured via stopper.
Produktspezifikationen
| Marke: | Proaim |
| Kategorie: | Stativ |
| Modell: | P-TNGO-01 |
