Operating Instructions
Reelcraft Industries, Inc. • 2842 E Business Hwy 30, Columbia City, IN 46725
Ph: 800-444-3134 / 260-248-8188 • Fax: 800-444-4587 / 260-248-2605
Customer Service: 855-634-9109 • [email protected] • www.reelcraft.com
Series 7000 Spring Driven Hose Reels
Low, Medium and High Pressure Model Numbers:
7600 OLP7830 OLP7925 OLP7830 OMP7600 OHP
7640 OLP7840 OLP7600 OMP7840 OMP7640 OHP
7650 OLP7850 OLP7630 OMP7850 OMP7650 OHP
7607 OLP7850 OLP1217640 OMP7400 OHP7650 OLP-HTH
7670 OLP7850 OLPSW577650 OMP7440 OHP7850 OLP-HTH121
7800 OLP7900 OLP7800 OMP7450 OHP7925 OLP-HTH
Read this manual carefully before installing, operating or
servicing this equipment.
IMPORTANT
Dimensions
A20 1/4”
B19 3/4”
C7 13/16”
D3 7/8”
E7”
• Ensure that reel is properly installed before connecting input and
output hoses.
• Bleed fluid/gas pressure from system before servicing reel.
• Before connecting reel to supply line, ensure that pressure does
not exceed maximum working pressure rating of reel.
• Remember, even low pressure is very dangerous and can cause
personal injury or death.
• Be aware of machinery and personnel in work area.
• If a leak occurs in the hose or reel, remove system pressure
immediately.
• A high tension spring assembly is contained within the reel.
Exercise extreme caution.
• Pull hose from reel by grasping the hose itself, not the control
valve.
• Ensure that reel, hose, and equipment being serviced are
properly grounded. Use an ohmmeter to check ground
continuity.
• If reel ceases to unwind or rewind, remove system pressure
immediately. Do not pull or jerk on hose!
• Treat and respect the hose reel as any other piece of machinery,
observing all common safety practices.
SAFETY
Personal injury and/or equipment damage may result if proper safety
precautions are not observed.
Form# 829-696A Rev: 1/2022
