CU6050LN CU6100LN

Operating Instructions

Series CU Air Hose Reels

Low Pressure Model Numbers:

Reelcraft Industries, Inc. • 2842 E Business Hwy 30, Columbia City, IN 46725

Ph: 800-444-3134 / 260-248-8188 • Fax: 800-444-4587 / 260-248-2605

[email protected] • www.reelcraft.com

Form# 1168-505 Rev: 7/2018

Read the following precautions and instructions before you begin assembly or using. Keep this literature in a dry place for future

reference.

Safety Precautions:

1. Make sure incoming pressure does not exceed 250 PSI.

2. Use the proper eye protection when assembling and using the hose reel.

3. Assemble the hose reel on a clean workbench free of debris and moisture.

4. Use soap and water when checking for air leaks.

5. Do not expose fingers or hands directly to a pressurized air hose or it will result in bodily injury.

6. Keep children away from the work area.

Unpacking:

When you receive your new air hose reel, it will be mostly assembled. Check to ensure that you have received the following loose parts:

Part No.QuantityDescription

602050 1 Swivel assembly replacement

602051 1 Crank handle

Installation:

Note: You must purchase hardware and air hose for mounting your new reel. Decide where you wish to mount reel before purchasing as

the hardware needed will vary provided different locations.

1. Match handle to the link lever and attach using handle assembly.

2. Apply teflon tape or pipe compound to swivel valve then thread the valve into the reel.

3. Put the bolts (3/8” or 10mm) through 4 holes in the base of the hose reel and tighten it to ceiling/wall/floor so reel can be fastened

into compressor.

4. Apply teflon tape or thread sealant to reel’s built in supply hose fitting. Then attach this supply hose to the outlet of air compressor.

5. Apply teflon tape or thread sealant to hose fitting threads. Attach to the reel swivel valve, then feed the rest of hose through the flange

opening.

6. To avoid damaging the swivel valve, make sure to use an appropriate wrench to stabilize the swivel and hosing tightening the hose

fitting.

Quality Guarantee:

Should this reel fail to perform satisfactorily due to defect or poor workmanship within one year of purchase, return

it to your place of purchase and it will be replaced or repaired free of charge. Incidental or consequential damages

are excluded from this warranty.

Specifications:

Capacity: CU6050LN - 50’ of 3/8” hose CU6100LN - 100’ of 3/8” hose

Air Inlet: 3/8” Brass NPT Hose Outlet: 3/8” Brass NPT

Maximum Pressure: 250 PSI
