Rocstor Y10A304-S1 Bedienungsanleitung
Seiten 2 USB-Hub
Lies die Bedienungsanleitung für Rocstor Y10A304-S1 kostenlos online oder lade das PDF herunter. 6 Personen fanden diese Anleitung hilfreich. Frage zu diesem Modell? Stelle eine Frage
Features
USB Type-C Male (Connect to a host computer)
Rocstor introduces a Type-C 4-in-1 hub featuring HDMI, USB-A, and Gigabit Ethernet
ports, oering an optimal solution for expanding the port options of Type-C/Thunder-
bolt 3 hosts, especially those with a single Type-C port. With its integrated captive
cable that can be conveniently wrapped at the bottom, this hub enhances user
experience and convenience. Utilizing the DP1.4 Alt mode supported IC, it enables
HDMI video output at a maximum resolution of 4k/60Hz while simultaneously
transferring USB 3.1 data at up to 5Gbps. Additionally, the Gigabit Ethernet port
ensures super-fast Ethernet connectivity. Compatible with all DP Alt mode supported
Type-C hosts, this hub provides versatile compatibility and seamless operation.
Before attempting to use this unit, please check the packaging and make sure the
following items are contained in the packaging:
• Main Unit x1
• User Manual
HDMI（DP Alt Mode Only）
• Supports max 4K/60Hz output with
18Gbps Bandwidth
• Supports 8/10 bit color depth output
• Supports output pixel format RGB /
YCbCr4:4:4/ YCbCr4:2:2/ YCbCr4:2:0
• Supports HDR ,HPD
• Supports HDCP 2.2&HDCP1.4
Note:When connecting a DP1.4 Alt mode
supported host, the max resolution of
HDMI is 4k/60Hz; When connecting a
DP1.2 Alt mode supported host, the max
resolution of HDMI is 4k/30Hz due to
bandwidth limitation
Upstream:
Downstream:
• Support DP1.4 Alt mode, with bandwidth max 2 lanes 16.2Gbps (8.1Gbps per lane),
downward compatible with DP1.2 Alt mode
Note:To get max bandwidth, the host should support DP1.4 Alt mode
USB-A X2
• Max 5Gbps data transmission per port
• Supports USB 3.0 Specication
• Supports short-circuit, over-current,
over-voltage protection
RJ45
• Supports Gigabit
Ethernet,10M/100M/1000M
• Supports Wake-On-LAN
• Supports full duplex ow control
• Light indicates the state, no
light when no Internet connected,
orange light turns on when network
connection is established, yellow light
ashes when transmitting data
Package Contents
Specication
Input
OutputHDMI Female p1-x1
USB-A Female x2
RJ45 x1
USB-C Male x1
3 Years
Operating Temperature
Storage Humidity
Storage Temperature
Operating Humidity
0°C to 45°C (32°F to 113°F)
10% to 90 % RH (no condensation)
-10°C to 70°C (14°F to 158°F)
10% to 90% RH (no condensation)
Introduction
Environmental
Input / Output Connector
Working Voltage
Working Current
4.75-5.3V
400mA-2700mA
2W
Electronic Parameter
Power Consumption
CerticationsFCC, CE
Regulatory Approvals
User ManualEnglish Version
Accessory Adapter
Warranty
Limited Warranty
Operating Temperature
Operating Temperature
Size
0°C to 45°C (32°F to 113°F)
mm
Mechanical
Weightg
®
Type-C to HDMI/USB-AX2/RJ45
with DP1.4 Alt mode
User Manual
Y10A304-B1
Congratulations
Thank you for purchasing this premium Rocstor product. For optimum performance and
safety, please read these instructions carefully before connecting, operating or using this
product. Please keep this manual for future reference.
