Satco Products, Inc.

Brentwood, NY 11717© Copyright 2024 Satco Products, Inc. 10/24 v3.0

1

LED T8/4' DOUBLE & SINGLE

ENDED BYPASS/LINE VOLTAGE

Models: S39917, S39918, S39919, S39920

INSTALLATION AND SAFETY INSTRUCTIONS

IMPORTANT: Read before installing xture. Retain for future reference.

Item Number-DescriptionVolts

Minimum Lamp

Compartment Dimensions

(Length x Width x Height)

Lamp

Quantity

Lamp-to-Lamp

Spacing

S39917-15T8/LED/48-830/BP/SE-DE

S39918-15T8/LED/48-835/BP/SE-DE

S39919-15T8/LED/48-840/BP/SE-DE

S39920-15T8/LED/48-850/BP/SE-DE

120-277V

48 1/2 x 13 1/2 x 1 7/8 inches

(1230 x 340 x 45 mm)

4

1 3/16 inches

(30mm)

Features, applications and installation

instructions continued on pages 2-4.

WARNING:

• DANGER: Risk of shock-disconnect power before

installation.

• WARNING: Risk of re or electric shock. LED

Retrot Kit installation requires knowledge of luminaire

electrical systems. If not qualied, do not attempt

installation. Contact a qualied electrician.

• WARNING: Product must be installed in accordance

with the national electrical code or your local electrical

code. If you are not familiar with these codes and

requirements, contact a qualied electrician.

• WARNING: Install this kit only in luminaries that have

the construction features and dimensions shown in the

photographs and/or drawing and where the input rating

of the retrot kit does not exceed the input rating of

the luminaire.

• WARNING: To prevent wiring damage or abrasion,

do not expose wiring to edges of sheet metal or other

sharp objects.

• WARNING: To avoid potential re or shock hazard, do

not use this retrot kit in luminaries employing shunted

bi-pin lampholders. NOTE: Shunted lamp holders are

found only in uorescent luminaries with instant-start

ballasts. Instant-start ballasts can be identied by the

words “Instant Start” or “I.S.” marked on the ballast.

This designation may be in the form of a statement

pertaining to the ballast itself, or may be combined

with the marking for the lamps with which the ballast

is intended to be used, for example F40T 12/IS, for

more information contact the LED luminaire retrot kit

manufacturer.

Do not make or alter any open holes in an enclosure of

wiring or electrical components during kit installation.

Installers should not disconnect the existing wire from

lampholder terminals to make new connections at

lampholder terminals. Instead installers should cut

existing lampholder leads away from the lampholder

and make new electrical connections to lampholder

lead wires by employing applicable connectors.

• WARNING: Luminaire wiring and electrical parts

may be damages when installing retrot kit hardware.

Check for enclosed wiring and components.

• WARNING: Check the existing wiring for damage

before installing upgrade kit. Do not install if existing

wires are damaged.

This retrot kit is accepted as a component of a

luminaire where the suitability of the combination shall

be determined by authorities having jurisdiction.

Type B Lamp – intended for operation in luminaires

with traditional uorescent-type lamp holders wired

directly to the branch circuit. This includes both

factory-wired luminaries as well as those converted for

this purpose under a retrot program.

THIS RETROFIT KIT INCLUDES, LED TUBE,

OPERATING INSTRUCTIONS, AND FIXTURE

LABEL FOR THE DOUBLE OR SINGLE ENDED

APPLICATION.

• “This luminaire has been modied and can no longer

operate the originally intended lamp,” shall be marked

on the retrot luminaire where readily visible by the

user during normal maintenance including lamping.

• Only use the control provided with or specied by

these instructions to control this lamp. This lamp

will not operate properly when connected to a

standard (incandescent) dimmer or dimming control.

Please consult with manufacture for detailed dimmer

information.

• Suitable for damp locations.

• Suitable for use in enclosed luminaries.

• Suitable for use with the following emergency

equipment; SATCO Products, Inc., model S8000,

5W Emergency LED Driver.

• This device complies with Part 15 of the FCC rules.

Operation is subject to the following two conditions:

(1) This device may not cause harmful interference,

and (2) This device must accept any interference

received, including interference that may cause

undesired operation.

The units covered by this report were intended to retrot surface mount, Type IC or non-IC recessed mount Listed uorescent

luminaires that use maximum 4 tubular lamps, the minimum lamp compartment dimensions are tabulated below.
