Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: June 2, 2020 2:48 PM

Product Diagram (IMC1GSFP60W)

ComponentFunction

1PWR LED

• An external is Green:DC Power Source

detected.

• An external is not O:DC Power Source

detected.

2RJ45 Port

• Connect a to the Network DeviceMedia

Converter.

• A (PD) is detected.ON: PoE Powered Device

• The is Flashing:Media Converter

transmitting/receiving data.

3DIP Switch

DIP1: This switch is currently not in use.

DIP 2:

• Sets SFP speeds to 1000Mbps (default) O:

• Sets SFP speeds to 100Mbps.On:

4SFP LED

• Indicates that a link is detected on the Green:

SFP.

• Indicates that data is being Flashing:

transmitted or received.

5SFP Slot

• Connect an (100/1000BASE-X) to the SFP

Media Converter.

64-Pin Terminal Block

• Connect an external (48-56V DC Power Source

DC Input) to the .Media Converter

• Connect an alarm or warning circuit to the

relay (ALM) connection. The relay is triggered if

the loses power.Media Converter

Industrial RJ45 to Open SFP Mini PoE Media Converter | 1000 Mbps (1G) | 60W

7Ground Screw

• Connect a ground connection to the Ground

ScrewDC Power Source when connecting a to

the .Media Converter

Requirements

For the latest requirements, please visit www.startech.com/IMC1GSFP60W

• Network Equipment (e.g. Router, Network Switch) x 1

• MSA-Compliant 100/1000BASE-X SFP Transceiver Module x 1

• RJ45 Terminated UTP/STP CAT5e (or better) Network Cable x 1

• Terminated Fiber Optic Cable (dependent on SFP Module) x 1

• DC Power Source x 1

• Small Flat Head Screwdriver x 1

• Phillips Head Screwdriver x 1

• Alarm or Warning Circuit x 1

Powering the Media Converter

Connecting and installing the must be completed by a 4-Wire Terminal Connector

licensed Electrician.

Notes: Make sure that you turn o the power source before connecting the power wire

to the .Media Converter

Do not exceed the recommend power source voltage as it may result in personal or

product damage.

1. Using a , loosen the two screws (+V-) on the Small Flat Head Screwdriver4-Wire

Terminal Connector (included).

2. Connect the from a (48 - 56V DC), or the provided Power WiresDC Power Source

Barrel Power Connector AdapterTerminal Block Connectors to the proper on

the. The terminals are marked on the Media ConverterMedia Converter’s Casing

(connect the positive wire to V+ and the negative wire to V-).

3. (Optional) Using a , loosen the two screws (ALM) on Small Flat Head Screwdriver

the .4-Wire Terminal Connector

4. (Optional) Connect the from an or to the Relay WiresAlarmWarning Circuit2

ALM Relay PinsTerminal Block Connector on the .

5. Tighten the four screws on the .4-Wire Terminal Connector

6. Insert the in the on the 4-Wire Terminal Connector4-Wire Terminal BlockMedia

Converter.

12

356

7

4
