Quick-Start Guide

To view manuals, FAQs, videos, drivers, downloads, technical drawings, and more, visit www.startech.com/support.

Manual Revision: October 7, 2019

Product Diagram (MCM10GSFP)

Front View:

Port/LEDFunction

1SFP+Media ConverterSFP+ Slot• Connect an to the .

2LEDs

• Link

• Solid Green: Link speed of 10G

• Power

• Solid Green: is receiving power.Media Converter

3RJ45 Port

• Connect an to the Ethernet Network DeviceMedia

Converter.

Note: The LED Indicators on the RJ45 port are inactive.

Rear View:

10GbE Fiber Media Converter | Open SFP+ Slot

1

Port/LEDFunction

45V DC Port

• Connect the to power the Universal Power Adapter

Media Converter.

Requirements

For the latest requirements, please visit .www.startech.com/MCM10GSFP

Installing the Media Converter

Connecting the Media Converter

1. Turn o the that will be connected to the Networking EquipmentMedia

Converter.

2. Remove the from the .Dust CoverSFP+ Slot

3. Insert an MSA-compliant 10GbE SFP+ module (sold separately) into the SFP+ Slot

on the Media Converter.

Note: The can only be used with 10GbE SFP+ Module.Media Converter

4. Remove the from the .Dust CoverSFP+ Module

5. Connect a (sold separately) to the on the Fiber-Optic CableFiber-Optic PortsSFP+

Module.

6. Connect the other end of the to the . Fiber-Optic CableFiber-Network Device

Note: For , the TX and RX connectors must be paired at Duplex Fiber Optic Cables

both ends of the connection. For example TX to RX, and RX to TX.

7. Connect a (sold separately) to the on the Cat 6/6a CableRJ45 PortMedia

Converter.

8. Connect the other end of the to the.Cat 6/6a Cable Ethernet Network Device

Powering the Media Converter

1. Connect the to the on the .Universal Power Adapter5V DC PortMedia Converter

2. Connect the other end of the to an . Universal Power AdapterAC Electrical Outlet

The (power) should light up solid green.PWR LED

3. Turn the from step #1 back on. Networking Equipment

2

4

3
