Issue 1
1 9471005
CAUTION: To reduce the risk of electric shock,
Do not remove cover.
No user serviceable parts inside.
Refer servicing to qualified service personnel.
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
This symbol indicates that dangerous
voltage constituting a risk of electric
shock is present within this unit.
This symbol indicates that there are
important operating and maintenance
instructions in the literature accompanying
this unit.
ezIP PoE ONE-WAY HORN
EZ-HR5
INTRODUCTION
The EZ-HR5 ezIP PoE One-Way Horn is a self-
contained paging system which enables voice
paging over an IP network. The EZ-HR5 consists
of a high efficiency horn and a Network Interface
allowing stand-alone capability when used with a
SIP telephone system or can be accessed from a
Valcom ezIP Page Controller, ezIP Interactive
Console, or by ezIP Page Group.The EZ-HR5 is
available in three colors, Beige, Gray and Marine
White. The Marine version features additional
weather protection.
SPECIFICATIONS
Access Methods
•SIP – enabled telephone system
•Valcom ezIP Page Controller
•Valcom ezIP Interactive Console
•Valcom ezIP Multicast Page Group
Features
•RJ-45 network connection
•Network activity LEDs
•Power over Ethernet (PoE) 802.3af compatible
•O-ring seal on bell housing (Marine model
only)
•Stainless steel hardware (Marine model only)
•Upgradable to full Valcom IP capability
Ordering Part Names
•EZ-HR5-GY for Gray Horn
•EZ-HR5-BGE for Beige Horn
•EZ-HR5-W for Marine White Horn
Dimensions/Weight
Horn
• 7.38” H x 10.0” W x 10.4” D
(18.75cm x 25.4cm x 26.42cm)
•Weight: 5.60 lbs. (2.54 kg)
Network Interface
•1.62” H x 5.63” W x 3.45” D
(4.11 cm) x (14.30 cm) x (8.73 cm)
with brackets– 8.22” W (20.87 cm)
•Weight: 2.10 lbs. (0.95 kg)
Nominal Power Requirements
Via 802.3af PoE Ethernet Switch:Class 3
Environment
Network Interface:
Temperature: 0 to +40° C
Humidity: 0 to 85% non-precipitating
PSE (Power Sourcing Equipment) to be compliant
to IEEE 802.3af
Indoor installation only
Horn:
Temperature: -20 to +55° C
Humidity: 0 to 95% non-condensing
Suitable for indoor or outdoor installation
INSTALLATION
Precautionary Designations
