1 9471004

CAUTION: To reduce the risk of electric shock,

Do not remove cover (or back).

No user serviceable parts inside.

Refer servicing to qualified service personnel.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates that dangerous

voltage constituting a risk of electric

shock is present within this unit.

This symbol indicates that there are

important operating and maintenance

instructions in the literature accompanying

this unit.

Issue 1

ezIP High Power One-Way Paging Horn

EZ-HR15-GY

INTRODUCTION

The EZ-HR15-GY ezIP One-Way Paging Horn

is a weather-resistant, high-efficiency horn

supporting SIP (Session Initiation Protocol) and

Valcom’s ezIP paging protocol, delivered via a

PoE-enabled IP network. The high-impact

Polycarbonate construction resists the

deteriorating effects of outdoor installation.

SPECIFICATIONS

Access Methods

•SIP telephone system

•Valcom ezIP Page Controller

•Valcom ezIP Interactive Console

•Valcom ezIP Multicast Page Group

Features

•Indoor / Outdoor use

•High Impact Polycarbonate Housing

•Omni-Directional Mounting Base

•SIP & Multicast Enabled

•Power over Ethernet (PoE) 802.3af and

802.3at (PoE+) compatible

•Remote Management & Monitoring

•Upgradable to full Valcom IP capability,

including full-duplex talkback

communication

Dimensions / Weight

•11.75” H x 10.0” W x 11.0” D (29.8cm H x

25.4cm W x 27.9cm D)

•4.3 lbs. (1.95 kg)

Audio Codecs

•G.722, G.711 (uLaw, aLaw)

Frequency Response

•350 Hz to 7kHz

Audio Dispersion

•120° Horizontal

•90° Vertical

Nominal Power Requirements

IEEE 802.3af (PoE) Class 3

IEEE 802.3at (PoE+) Class 4

These products are intended for use with a UL

Listed power source marked “Class 2” or “LPS”

rated 24 Vdc, or 48 Vdc (PoE).

PoE and all interconnected ITE are intended for

intra-building.

Environment

Temperature: - 20° to +50° C

Humidity: 0 - 95% non-condensing
