1 947574

CAUTION: To reduce the risk of electric shock,

Do not remove cover (or back).

No user serviceable parts inside.

Refer servicing to qualied service personnel.

CAUTION

RISK OF ELECTRIC SHOCK

DO NOT OPEN

This symbol indicates that dangerous

voltage constituting a risk of electric

shock is present within this unit.

This symbol indicates that there are

important operating and maintenance

instructions in the literature accompanying

this unit.

Issue 2

VIP--IC, VIP--- 422A422AICV4

InformaCast

®

Compliant

LAY-TALKBACK IP CEILING SPEAKER IN

INTRODUCTION

The VIP-422A- and VIP-422A-- InformaCast ICICV4

Compliant - Talkback IP Ceiling Speakers LayIn

enable voice access to a single zone paging over of

an IP-based network.The speaker output level is

controlled by the InformaCast server. The lay-in

ceiling speaker grille is made of steel with a white

baked enamel nish. The VIP-2A- replaces a 42IC

2’ x 2’ ceiling tile. Power is provided to the unit via

a Power over an Ethernet (PoE) switch meeting the

802.3af specication.The -V4 model is identical in

t, form and function to the non -V4 model.

SPECIFICATIONS

Access Methods

•Singlewire InformaCast Server

•SIP enabled telephone system –

•Valcom M Cast Page Group

Features

•Full Duplex Communication (-V4 only)

•Ambient Noise Adjustment (-V4 only)

•Power over Ethernet (PoE) 802.3af compliant

•High Eiciency Class-D Amplier ff

Environment

Temperature: 0 to +40° C

Humidity: 0 to 85% non-precipitating

These products are intended for use with a UL

Listed power source marked “Class 2” or “LPS”

rated 24VDC, or 48VDC (PoE).

PoE and all interconnected ITE are intended for

intra-building.

Dimensions/Weight

•23.L x 23. W x D 75” 75”3.75”

(60.33 cm) x (60.33 cm) x (9.53 cm)

•Weight: 5.5 lbs. (2.49kg)

FCC Information

This equipment has been tested and found to

comply with the limits for a Class A digital

device, pursuant to Part 15 of the FCC Rules.

These limits are designed to provide reasonable

protection against harmful interference when

the equipment is operated in a commercial

environment. This equipment generates uses,

and can radiate radio frequency energy and if

not installed and used in accordance with the

instruction manual, may cause harmful

interference to radio communications.

Operation of this equipment in a residential area

may cause harmful interference in which case

the user will be required to correct the

interference at his own expense.

Precautionary Designations
