Seite 1/2
1. Check to be sure your power source is capable of handling the voltage
requirements of the motor, as indicated on the pump name plate.
2. These pumps are not designed or intended to be used to handle sewage
or efuent.
3. This pump has been evaluated for use with WATER only.
4. Maximum continuous operating water temperature for standard model
pumps must not exceed 104 °F (40 °C).
5. These pumps are not designed or intended to be used as a primary or
backup sump pump.
Note: Pumps with the "CSA" mark are tested to CSA Standard C22.2 No. 108.
REFER TO WARRANTY ON PAGE 2.
PERFORMANCE
Your pump is designed to effectively pump all clear storm and drain waters.
Although it will usually pass small particles suspended in water; grass, heavy
mud, sand or pea gravel can clog the pump and reduce pump performance.
This can usually be cleaned out by backushing with a garden hose through
the discharge. The normal performance that can be expected is as follows:
MODEL HP
GALLONS PER HOUR AT
DISCHARGE HEIGHT ABOVE
PUMPING LEVEL
SHUT-OFF
HEAD
5 ft 10 ft 15 ft
42 1/6 900 660 360 20 ft
44 1/4 1800 1320 720 20 ft
46 1/2 3300 2820 2160 34 ft
DO NOT USE FOR PUMPING OILS, GASOLINE OR ANY PETROLEUM BY-PRODUCTS.
Notice to Installer: Instructions must remain with installation.
1. Inspect your pump. Occasionally, products are damaged during shipment. If the unit is damaged, contact your dealer before
using. DO NOT remove the test plug in the cover.
2. Carefully read the literature provided to familiarize yourself with specic details regarding installation and use. These materials should be retained
for future reference.
1. Make sure there is a properly installed ground fault circuit interrupter (GFCI)
protected circuit available. All pumps are furnished with provisions for
proper grounding to help protect you against the possibility of electrical
shock.
2. Make certain that the ground fault receptacle is within the reach of the
pump’s power supply cord. DO NOT USE AN EXTENSION CORD. Extension
cords that are too long or too light do not deliver sufcient voltage to the
pump motor. But, more important, they could present a safety hazard if
the insulation were to become damaged or the connection ends were to
fall into water.
3. Make sure the pump electrical supply circuit is equipped with fuses
or circuit breakers of proper capacity. A separate branch circuit is
recommended, sized according the National Electrical Code for the current
shown on the pump name plate.
4. TESTING FOR GROUND. As a safety measure, each electrical outlet should
be checked for ground using an Underwriters Laboratory Listed circuit
analyzer which will indicate if the power, neutral and ground wires are
correctly connected to your outlet. If they are not, call a qualied licensed
electrician.
5. Installation and checking of electrical circuits and hardware should only
be performed by a qualied licensed electrician.
6. FOR YOUR PROTECTION, ALWAYS DISCONNECT PUMP FROM ITS POWER
SOURCE BEFORE HANDLING.
7. These pumps are supplied with a 3-prong grounded plug to help protect
you against the possibility of electrical shock. DO NOT UNDER ANY
CIRCUMSTANCES REMOVE THE GROUND PIN. The 3-prong plug must be
inserted in a mating 3-prong fault interrupter receptacle. If the installation
does not have such a receptacle, it must be changed to the proper type,
wired, and grounded in accordance with the National Electrical Code and
all applicable local codes and ordinances.
8. Risk of electric shock. This pump has not been tested for use in swimming
pool or marine areas.
9. Prop65 Warning for California residents: Cancer and Reproductive harm-
www.P65Warnings.ca.gov.
CAUTION
SEE BELOW FOR LIST OF
CAUTIONS
SEE BELOW FOR
LIST OF WARNINGS
INSTALLATION INSTRUCTIONS
MODEL: N42, LM44, N44, N46
PREINSTALLATION CHECKLIST - ALL INSTALLATIONS
FM2427
0219
Supersedes
1016
© Copyright 2019 Zoeller
®
Co. All rights reserved.
P/N 022508
Product information presented
here reects conditions at time
of publication. Consult factory
regarding discrepancies or
inconsistencies.
MAIL TO: P.O. BOX 16347 • Louisville, KY 40256-0347
SHIP TO: 3649 Cane Run Road • Louisville, KY 40211-1961
TEL: (502) 778-2731 • 1 (800) 928-PUMP • FAX: (502) 774-3624
Visit our web site:
zoellerpumps.com
Register your
Zoeller Pump Company
Product on our website:
http://reg.zoellerpumps.com/
DATE INSTALLED:
MODEL NUMBER:
NOTE: Ratings based on 1-1/4" pipe with friction loss neglected. Using 3/4"
garden hose adapter, performance will be reduced approximately 15%. This
pump does not deliver enough pressure to operate lawn sprinklers properly.
OPERATION
1. Set pump on hard surface in water before starting.
2. Use the included garden hose adapater for 3/4" discharge line or disconnect
the adapter to use a 1-1/4" discharge.
3. Plug power cord into properly grounded 115 volt AC power outlet. (See
recommended grounding methods on front page). Will operate continuously
whether partly or fully submerged. Submersible utility pumps are intended
to pump water at temperatures up to 104 ˚F (40 ˚C).
For automatic model LM44 only:
4. When the pump senses that it is no longer pumping water, the pump
will shut off automatically. The pump will then turn on every three
minutes for 5 seconds and then off if it does not sense any water.
5. If water is sensed after the pump begins running, the pump will
continue pumping until the pump senses that it is no longer
pumping water.
6. Unplug the pump from the power output when not in use.
7. The pump is supplied with a 3/4" garden hose adapter. For
use with plastic pipe, remove the adapter and install the desired
1-1/4" NPT tting. DO NOT OVERTIGHTEN THE HOSE OR PLASTIC ADAPTER
FITTING. Finger tight plus 1/2 turn is sufcient.
CAUTION
Do not set pump directly on sand, dirt or mud. Sand or
mud-choked pumps can be back-ushed clean.
CAUTION
Do not handle or carry the pump by the power cord.
Use the handle.
CAUTION
Extended usage of the pump in a partially submerged
or non-submerged situation may cause the pump to
overheat due to lack of heat dissipation from the water. If this occurs, the pump
will shut itself off until the motor cools to its normal temperature. Repeated
overheating may cause damage to the pump.
MAINTENANCE
1. The motor housing of the pump is completely sealed and requires no
service. Disassembly of the motor housing or alteration of the power cord
voids all warranty.
2. The motor is a continuous duty type with an automatic thermal overload
protector device.
3. The pump can run against a partially restricted discharge, but is designed
to move large volumes of water with minimal back pressure.
4. If the pump becomes clogged, remove the screen and clean out the area.
5. Debris in the intake should be routinely removed from the bottom of the pump
to prevent damage to the pump, which will void the warranty.
6. If necessary, remove the eight (8) screws holding the volute base to the
motor housing and clean the volute.
Manufacturer warrants, to the purchaser and subsequent owner during
the warranty period, every new product to be free from defects in material
and workmanship under normal use and service, when properly used
and maintained, for a period of two year from the date of purchase. Proof
of purchase is required. Parts that fail within the warranty period, that
inspections determine to be defective in material or workmanship, will be
repaired, replaced or remanufactured at Manufacturer's option, provided
however, that by so doing we will not be obligated to replace an entire
assembly, the entire mechanism or the complete unit. No allowance will
be made for shipping charges, damages, labor or other charges that may
occur due to product failure, repair or replacement.
This warranty does not apply to and there shall be no warranty for any
material or product that has been disassembled without prior approval
of Manufacturer, subjected to misuse, misapplication, neglect, alteration,
accident or act of God; that has not been installed, operated or maintained
in accordance with Manufacturer's installation instructions; that has been
exposed to outside substances including but not limited to the following:
sand, gravel, cement, mud, tar, hydrocarbons, hydrocarbon derivatives (oil,
gasoline, solvents, etc.), or other abrasive or corrosive substances, wash
towels or feminine sanitary products, etc. in all pumping applications. The
warranty set out in the paragraph above is in lieu of all other warranties
LIMITED WARRANTY
expressed or implied; and we do not authorize any representative or other
person to assume for us any other liability in connection with our products.
Contact Manufacturer at, 3649 Cane Run Road, Louisville, Kentucky 40211,
Attention: Customer Service Department to obtain any needed repair or
replacement of part(s) or additional information pertaining to our warranty.
MANUFACTURER EXPRESSLY DISCLAIMS LIABILITY FOR SPECIAL,
CONSEQUENTIAL OR INCIDENTAL DAMAGES OR BREACH OF EXPRESSED
OR IMPLIED WARRANTY; AND ANY IMPLIED WARRANTY OF FITNESS
FOR A PARTICULAR PURPOSE AND OF MERCHANTABILITY SHALL BE
LIMITED TO THE DURATION OF THE EXPRESSED WARRANTY.
Some states do not allow limitations on the duration of an implied warranty,
so the above limitation may not apply to you. Some states do not allow
the exclusion or limitation of incidental or consequential damages, so the
above limitation or exclusion may not apply to you.
This warranty gives you specic legal rights and you may also have other
rights which vary from state to state.
© Copyright 2019 Zoeller
®
Co. All rights reserved.
MAIL TO: P.O. BOX 16347 • Louisville, KY 40256-0347
SHIP TO: 3649 Cane Run Road • Louisville, KY 40211-1961
(502) 778-2731 • 1 (800) 928-PUMP • (502) 774-3624FAX
Visit our web site:
zoellerpumps.com
In instances where property damages are incurred as a result of an alleged product failure,
the property owner must retain possession of the product for investigation purpose.
