Operation Manual

Back-UPS

™

ES 550/700

Connect the Battery

The Back-UPS is shipped with one battery cable disconnected. Remove the “Stop! Connect the Battery” label that covers the

outlets. Prior to connecting any equipment to the unit, connect the battery cable to the unused battery terminal. It is normal for

small sparks to be seen when the battery cable is connected to the battery terminal.

Wall Mount Installation

The UPS can be installed vertically or horizontally to a wall. Use the template to assist with installation and a fastener (not

included) that can support at least 6.8 kg.

1.Hold the template against the wall surface and use a nail or pin to mark the center of each hole.

2.Install a fastener into the wall at the marked locations. Allow 8 mm of the fastener to protrude from the wall.

3.Install the unit on the wall, using the fasteners.

InventorySafety and General Information

Inspect the package contents upon receipt. Notify

the carrier and dealer if there is any damage.

Read the Safety Guide supplied with this unit before

installing the UPS.

• This UPS is intended for indoor use only.

• Do not operate this UPS in direct sunlight, in contact with fluids, or where there is

excessive dust or humidity.

• Be sure the air vents on the UPS are not blocked. Allow adequate space for proper

ventilation.

• The battery typically lasts for two to three years. Environmental factors impact battery life.

Elevated ambient temperatures, poor quality AC power, and frequent short duration

discharges will shorten battery life.

• Connect the UPS power cable directly to a wall outlet. Do not use surge protectors or

extension cords.

Charge the battery for at

least 16 hours before

use.

bu075c

Back-UP

S

User Documentation

bu034a

bu035a

b

u036a

165 mm

(6.50 in.)

Wall-mounting Template
