Seite 1/4
5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
Banquet Cabinets
FL-2247
Rev. 2 (8/10) Page 1 of 4
OPERATING and MAINTENANCE INSTRUCTIONS
for CCB-96A and CCB-120A Banquet Warming Cabinets
Volts Watts Amps Hertz Phase Serv. NEMA *NEMA
120 1650 13.8 60 1 AC 5-15P 5-20P
240 1650 6.9 60 1 AC 6-15P 6-15P
* For Canadian use
HOW TO INSTALL UNIT:
1. Remove all packing materials from inside the
cabinet.
2. Install all angles and shelves before the unit is
turned on.
3. Plug the power cord into the proper wall outlet.
HOW TO TURN OFF UNIT:
Push power switch to “OFF”.
HOW TO START UNIT:
1. Push the power switch to “ON”. Yellow light will
turn on.
2. Turn the thermostat to #10 (220°F/105°C).
3. Preheat (assuming a “cold” cabinet of 75°F/25°C)
a) To 150°F/65°C takes 20 minutes
b) To 200°F/95°C takes 40 minutes
c) To 220°F/105°C takes 1 hour.
4. Put food into the cabinet.
5. Turn the thermostat to the temperature you need.
NOTE: No. 5 setting is approximately 150°F/65°C.
Proper food holding temperature is
140°F/60°C or higher.
REMOVABLE HOT UNIT
PARTS IDENTIFICATION
1. Thermostat
2. Power Switch
3. Yellow Indicator Light
4. Temperature Display
ON
OFF
1 2 3 4
5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
Banquet Cabinets
FL-2247
Rev. 2 (8/10) Page 2 of 4
OPERATING and MAINTENANCE INSTRUCTIONS
for CCB-96A and CCB-120A Banquet Warming Cabinets
BEFORE
CLEANING THE CABINET:
1. Allow cabinet to cool.
2. Remove Hot Unit BEFORE cleaning. (Unit
is designed to lift o from front and rear.)
3. Do NOT use abrasives or harsh chemicals.
HOW TO CLEAN THE UNIT:
Soil Cleaner Method
CABINETS
(Stainless Steel)
Routine Cleaning Soap, ammonia, or
detergent* and water
1. Sponge on with cloth.
2. Rinse.
Stubborn spots
and stains
Mild abrasive made for
stainless steel
1. Apply with damp cloth.
2. Rub lightly.
Burnt-on foods or
grease.
Chemical oven cleaner 1. Apply generous coating.
2. Allow to stand for 10-15
minutes.
3. Rinse.
4. Repeat application if
necessary.
Hard water spots
and scale.
Vinegar 1. Swab or wipe with cloth.
2. Rinse dry.
*Mild detergents include soaps and non-abrasive cleaners.
Cleaning Notes:
1. Wipe up spills as soon as possible.
2. Clean cabinet regularly to avoid heavy dirt build-up.
3. Make a test spot with cleaner.
4. Follow manufacturer’s directions on cleaner.
5. Do not mix cleaners.
6. Avoid drips and splashes.
REMOVABLE PARTS
IDENTIFICATION
1. Wire Grids
2. Pan Slides
3. Hot Unit
4. Air Tunnels
5. Posts for Pan Slides
WARNING
1
2
3
4 5
5925 Heisley Road • Mentor, OH 44060-1833
Call Toll-free: 877-CRES COR (273-7267) • Fax: 800-822-0393 • www.crescor.com
Banquet Cabinets
FL-2247
Rev. 2 (8/10) Page 3 of 4
OPERATING and MAINTENANCE INSTRUCTIONS
for CCB-96A and CCB-120A Banquet Warming Cabinets
TROUBLE-SHOOTING CHART:
FAILURE POSSIBLE CAUSE
1. Yellow light at switch does NOT light.
1a. Circuit breaker/fuse to wall outlet blown.
2a. Cord is unplugged from wall outlet.
3a. Switch is “OFF.”
2. Unit does not get hot.
2a. Thermostat set too low or are off.
2b. Switch is “OFF.”
3. Unit gets too hot or won’t shut off
3a. Defective electrical parts.
3b. UNPLUG UNIT FROM WALL OUTLET
4. Blower does not work or makes noise. 4a. Defective Blower
5. Excess moisture in cabinet.
5a. Foods taken from oven or fryer should be “slacked
out” for 5 minutes before placing in hot cabinet.
NOTE: Optional digital thermometer will fl ash if cabinet temperature is below 140°F or above 250°F.
Call the Factory if you need dierent settings.
If cause is none of the above, refer to our list of Authorized Service Centers, FL-1400.
REPLACEMENT PARTS:
CABINET PARTS:
DESCRIPTION 120 VOLT 240 VOLT DESCRIPTION PART NO.
Hot Unit HU18671-184* HU18671-185 Door Latch Kit 1006-143-K
Terminal Block 0852-091 0852-091 Latch Strike 1006-144-K
Blower Kit 0769-180-K 0769-182-K Door Gasket, CCB-96A 0861-173
Heater Kit 0811-214-01 0811-215-01 Door Gasket, CCB-120A 0861-172
Thermostat Kit 0848-062-K 0848-062-K Door Hinge 0519-084
Thermometer Kit 5238-030-K 5238-030-K Push Handle 1072-089
Power Cord 0810-029-02* 0810-039-03 Wire Grid 1170-095
Switch Kit 0808-116-K 0808-116-K Door Assembly, CCB-96A 1221-460-K
Door Assembly, CCB-120A 1221-461-K
For Canadian Use:*
Hot Unit (120 Volt) HU18671-184C
Power Cord Plug 0713-017
Thermometer Kit, °C 5238-024-01
