Assembly Instructions: (Bijoux)1998-5/5SF
IMPORTANT:
•ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.
•SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!
•USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!
PREPARING FOR INSTALLATION
Remove all of the contents from the carton. See the important notes
above. Remove the old xture from the ceiling, including the old
mounting strap.
1. Take the mounting strap assembly from the parts bag. One end of
nipple (F) should be attached to mounting strap (A) with washer and hex
nut (C) and (D) in place. Canopy loop (H) should be on the other end.
2. Use a screwdriver and mounting screws (B) to attach mounting strap
(A) to the junction box. (Note: When mounting strap (A) is properly
installed, about half of the exterior threads of nipple (F) are exposed,
allowingcanopyloop(H)totsnuglyontonipple(F).Youmaywantto
testtoensurethatwithcanopy(G)inplace,canopyloop(H)tsonto
nipple (F). After testing, remove everything from the nipple and place
aside for later.) until the desired height is reached.
CLEANING TIPS
Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the
xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.
For Customer Service, please
contact the place of purchase.
FINISHING THE INSTALLATION
6. Push canopy (G) up to the ceiling and slide canopy loop collar (I) up beneath the canopy. Tightly thread canopy loop collar (I) onto
canopy loop (H) to secure canopy (G) in place.
7.Slidecandlesleeves(O)overthesockets.Installlightbulbsinaccordancewiththexture’sspecications.Donotexceedthemaximum
wattage.
8.Yourinstallationisnowcomplete.Turnonthepowerandtestthexture.
3.Placeshade(N)ontoaatsurface.Threadtoploop(L)ontopost
(M). Measure to determine the correct number of chain links (J) needed
for proper hanging height. If necessary, use a pair of pliers to open and
remove any excess chain. For the semi-ush installation, thread the wires
through canopy (G). Open one of chain connectors (K) and use it to connect
directly top loop (L) to canopy loop (H).
CONNECTING THE WIRES
5.Haveanassistantsupportthexture’sweightwhilecompletingthewiring.Cut
awaytheexcesswires.Threadthexture’swiresthroughthecanopyloopand
nipple.Refertothewiringdiagramandattachthexture’swirestothepower
supply wires from the junction box. Connect Hot to Hot, Neutral to Neutral, and
Ground to Ground. Twist the ends of the wire pairs together, and then twist on
a wire connector. Make sure all twists are in the same direction. If there is no
house ground wire coming from the junction box, locate ground screw (E) on
themountingbracket/mountingstrapandwrapthexture’sgroundwirearound
the ground screw. Use a screwdriver to tighten the top of ground screw (E) onto
the wires and into the mounting bracket/mounting strap. Tuck the wires into the
junction box.
How to Identify the Fixture’s Wires
HotNeutralGround
Smooth
Ribbed
Bare Metal,
Green, or
Green Inner
Thread
Black
White
Black Inner
Thread
White Inner
Thread
House Wires
Fixture Wires
Hot
4. Attach one of chain connector (K) to each end of chain (J). Use one of chain connectors (K) to attach chain (J) to top loop (L) and close
thechainconnector.Feedthexture’swiresupthroughthechain(everythreelinksorso),pullingthewiresuntiltaut.Slidecanopyloop
collar (I) and canopy (G) onto the chain and wires. Use the free chain connector (K) to attach chain (J) to canopy loop (H).
A
C
B
F
G
D
K
K
E
H
L
M
N
O
J
I
Produktspezifikationen
| Marke: | Golden Lighting |
| Kategorie: | Beleuchtung |
| Modell: | Bijoux 1998-5SF |
