Mounting

Strap

Mounting screw

Stem With Hex

Nut

1ea

L4"*H1.5mm

4ea 8/32-IP*H1"1ea @3/8 x 110mm

Hex nutWire connnectorDeco Nut

3 ea P4 Orange

Bottom capFinial

Flat Washer/Rubber

Washer

Part NeededQuantity

Part NeededQuantity

Reason why( missing, scratched, broken glass, bent, bad finish)

Comments

For Customer Service, contact the place of purchase to arrange for replacement parts.

NOTE: INSTALL THE GLASS ASSEMBLY

AFTER THE FIXTURE IS HUNG.

1. Thread the Stem With Hex Nut (G) into the Coupling

of the Ceiling Pan (F) until tight.

2. Install the lighting bulbs in accordance with the

fixture's specification.

3. Place the Flat Washer (H), Rubber Washer (I),

Glass Shade (J), Rubber Washer (I), Scrolled cage (K)

over the Stem (G) and thread Hex Nut (L) on until

tight.

4. Slide Bottom Cap (M) over Stem With Hex Nut (G)

and thread the Finial (N) until tight.

(DO NOT EXCEED MAXIMUM WATTAGE RATING!)

Fig 1

1821-FM BI

Read and review installation instruction sheet

before assembling the fixture.

PARTS & ASSEMBLY SHEET

This fixture assembled PO:__________ Date: ________

Fixture Name: Madera 1821-FM BI

1ea / 2ea

3/8-IP*H3mm / 8/32-IP*H3mm

Notice:

Please review the parts listing and check for all parts before assembling the fixture. If any parts are missing or

damaged, please note on this sheet and contact the place of purchase to arrange for replacement parts.

PARTS LIST

Company Name:_______________________Co. Account #:_____________

to be filled out by retailer

2ea 12mmx 11mm

F

IXTURE

A

SSEMBLY

I

NSTRUCTIONS

1ea/2ea @1-1/2" x 2mm1ea Φ75*H14mm1ea 3/8-IP*H14mm

F

G

H

I

J

K

I

L

N

M
