Assembly Instructions: (Leighton)8401-LP
IMPORTANT:
•ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.
•SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!
•USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!
PREPARING FOR INSTALLATION
Removeallofthecontentsfromthecarton.Seetheimportantnotesabove.Removetheoldxturefromtheceiling,includingtheold
mounting strap.
1. Take the mounting strap assembly from the parts bag. One end of nipple (F) should be attached to mounting strap (A) with a washer and
2.Useascrewdriverandmountingscrews(B)toattachmountingstrap(A)tothejunctionbox.
CLEANING TIPS
Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the
xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.
For Customer Service, contact
the place of purchase.
FINISHING THE INSTALLATION
9.Pushthecanopyuptotheceiling.Tightlythreadnial(I)ontothe
threads of nipple (F) to secure the canopy in place.
10.Installlightbulbs(notprovided)inaccordancewiththexture’s
specications.
Donotexceedthemaximumrecommended
wattage.
Yourinstallationiscomplete.Turnonthepowerandtestthexture.
ASSEMBLING THE FIXTURE
3.Placelantern(M)onaatsurface.Placespacers(P)overposts(V)andthreaddecorativescrews(Q)intoposts(V).Placelampbodies
(U) close to lantern (M).
4.Rods(N)areonthexture’swires,butnotattachedtolampbodies(U).Pullthewiresuntiltautandthreadthebottomofrods(N)onto
posts(O).Positionlampbodies(U)insidelantern(M).Pushthexture’swiresfollowedbypost(T)ofrods(N)throughtheholeslocatedat
the top of lantern (M).
CONNECTING THE WIRES
8.Haveanassistantsupportthexture’sweightwhilecompleting
the wiring.Cutawaytheexcesswires.Refertothewiring
diagrambelowandattachthexture’swirestothepowersupply
wiresfromthejunctionbox.ConnectHottoHot,Neutralto
Neutral,andGroundtoGround.Twisttheendsofthewirepairs
together,andthentwistonawireconnector.Makesurealltwists
are in the same direction. If there is no house ground wire coming
fromthejunctionbox,locategroundscrew(E)onthemounting
bracket/mountingstrapandwrapthexture’sgroundwirearound
the ground screw. Use a screwdriver to tighten the top of ground
screw (E) onto the wires and into the mounting bracket/mounting
strap.Tuckthewiresintothejunctionbox.
House Wires
Fixture Wires
Hot
How to Identify the Fixture’s Wires
HotNeutralGround
Smooth
Ribbed
Bare Metal,
Green, or
Green Inner
Thread
Black
White
Black Inner
Thread
White Inner
Thread
5.Slidetoploops(L)ontothexture’swiresandthreadontopost
(T) to attach lamp bodies (U) to lantern (M).
6.Bymeasuring,determinethecorrectnumberofchainlinks
neededforproperhangingheight.Ifnecessary,useapairof
plierstoopenandremoveanyexcesschain.Additionalchain
may be ordered through the place of purchase.
7. Attach chain connectors (K) to each end of chains (J) before
attaching one end of the chain connector/chain to top loops
(L).Closethechainconnectors.Feedthexture’swiresthrough
top loops (L) then through chain (J) (every three links or so). Pull
the wires until taut. Pass the wires through the holes at canopy
loops (H). Connect the loose ends of chains (J) to canopy (G) by
attaching chain connectors (K) to canopy loops (H).
O
P
A
B
C
D
E
F
G
H
I
J
K
K
M
L
N
S
R
Q
T
U
V
Junction Box
