Assembly Instructions: (Manhattan)2243-SF

IMPORTANT:

•ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.

•SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!

•USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!

PREPARING FOR INSTALLATION

Remove all of the contents from the carton. See the

important notes above. Shut off the power at the circuit

breakerandcompletelyremovetheoldxturefromthe

ceiling, including the old mounting strap.

1. Mounting strap (B) contains several pairs of threaded

holes. Find the pair of holes that matches the spacing of

theholesonthejunctionboxandyourxture’scanopy.

Test canopy (G) on mounting strap (B) to ensure that the

canopy will hang straight with enough of the threads

ofmountingscrews(A)exposedfordeconuts(F)tot

securely.Placethextureaside.Pullthehousewires

through the center of mounting strap (B).

2.Placemountingstrap(B)overthejunctionboxsothat

mounting screws (D) may be inserted. Secure mounting

strap(B)tothejunctionboxwithmountingscrews(D)

and a screwdriver. Tighten the screws securely.

CLEANING TIPS

Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and

wipe down the xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.

For Customer Service, please

contact the place of purchase.

House Wires

Fixture Wires

Hot

How to Identify the Fixture’s Wires

HotNeutralGround

Smooth

Ribbed

Bare Metal,

Green, or

Green Inner

Thread

Black

White

Black Inner

Thread

White Inner

Thread

CONNECTING THE WIRES

3.Haveanassistantsupportthexture’sweightwhilecompletingthewiring.Cutawayexcesswire.Pullthexture’swires

throughthecanopy.Attachthexture’swirestothepowersupplywiresfromthejunctionbox.Connectblacktoblack(or

smooth); white to white (or ribbed); ground to ground (green or copper). Twist the ends of the wire pairs together, and then twist

on a wire connector. Make sure all twists are in the same direction. If there is no ground wire (green or copper) coming from the

junctionbox,locategroundscrew(E)onthemountingstrapandwrapthexture’sgroundwirearoundthegreengroundscrew

(E).Useascrewdrivertosecuregroundscrew(E)ontothemountingbracket.Tuckallwiresneatlyintothejunctionbox.

FINISHING THE INSTALLATION

4. Push canopy (G) up to the ceiling over mounting strap (B) so that mounting screws (A) protrude through the holes in the

canopy.Tightlythreaddecorativenuts(F)ontotheexposedthreadsofmountingscrews(A)tosecurecanopy(G)inplace.

5. Carefully slide candle sleeves (H) over sockets (I).

6.Installbulbs(notprovided)inaccordancewiththexture’sspecications.Donotexceedthemaximumwattage.

Yourinstallationisnowcomplete.Turnonthepowerandtestthexture.
