Assembly Instructions: (Wesson)2072-M1L
IMPORTANT:
•ALL INSTALLATION WORK SHOULD BE DONE BY ACCREDITED PROFESSIONAL.
•SHUT OFF POWER SUPPLY AT FUSE OR CIRCUIT BREAKER!
•USE ONLY THE SPECIFIED BULBS. DO NOT EXCEED THE MAXIMUM WATTAGE!
CLEANING TIPS
Treat the xture gently! Regular cleaning will reduce the need for deep cleaning. For regular cleaning, turn off the light and wipe down the
xture with a clean lint-free cotton or microber cloth. Never spray cleaner directly onto the xture.
For Customer Service, please
PREPARING FOR INSTALLATION
Remove all of the contents from the carton. See the important notes above. Remove the
oldxturefromtheceiling,includingtheoldmountingstrap.
1.Takethemountingstrapassemblyfromthepartsbag.Mountingstrap(B)contains
threadedholes.Twoofmountingscrews(A)shouldbeattachedtomountingstrap(B).
Youmayneedtotightennuts(C)thatholdthesescrewsinplace.
2.Placemountingstrap(B)overthejunctionboxsothatmountingscrews(A)are
vertical,andinalignmentwiththeholelocationsonthexture’scanopy(F).Secure
mountingstrap(B)tothejunctionboxwithmountingscrews(D)andascrewdriver.
Tightenthescrewssecurely.
ASSEMBLING THE FIXTURE
3.Measuretodeterminethecorrectnumberofrodsneededforhanging.Rods(LandK)
areonthexture’swires.Bymeasuring,determinethecorrectnumberofrodsneeded
forproperhangingheight.Thereare3optional12inchrods(L)andone6inchrod(K)
included.Youmustuseatleastone12inchrodorone6inchrod.
4.Toshortenthexture,trimthewirestothedesiredlengthaddingatleast8to10
inchesofwiretothedesiredlength.Slideanyexcessrodsoffthexture’swiresto
discard.Tolengthenthexture,addadditionalrods.Ifadditionalrodsareneeded,
contact the place of purchase to order.
5.Threadthexture’swiresthroughtherodsandpullthewiresuntiltautbeforethreading
therodstogether.
6.Threadbottomrod(LorK)ontopost(M)atthetopofthexture’sbody.Twisttoprod
(L or K) into the threads of swivel post (G) of canopy (F).
7.Locktherodinplacebytwistingscrew(I).Pullthexture’swiresthroughtheswivel
and the top of canopy (F).
CONNECTING THE WIRES
8.Haveanassistantsupportthexture’sweightwhilecompletingthewiring.Cutaway
theexcesswires.Refertothewiringdiagramandattachthexture’swirestothepower
supplywiresfromthejunctionbox.ConnectHottoHot,NeutraltoNeutral,andGround
toGround.Twisttheendsofthewirepairstogether,andthentwistonawireconnector.
Makesurealltwistsareinthesamedirection.Ifthereisnohousegroundwirecoming
fromthejunctionbox,locategroundscrew(E)onthemountingbracket/mountingstrap
andwrapthexture’sgroundwirearoundthegroundscrew.Useascrewdrivertotighten
thetopofgroundscrew(E)ontothewiresandintothemountingbracket/mountingstrap.
Tuckthewiresintothejunctionbox.
FINISHING THE INSTALLATION
9.Pushcanopy(F)uptotheceilingandtightlythreadnuts(H)ontotheexposedthreads
mountingscrews(A).
10.Installalightbulbinaccordancewiththexture’sspecications.Donotexceedthe
maximumrecommendedwattage.
Yourinstallationiscomplete.Turnonthepowerandtestthexture.
How to Identify the Fixture’s Wires
HotNeutralGround
Smooth
Ribbed
Bare Metal,
Green, or
Green Inner
Thread
Black
White
Black Inner
Thread
White Inner
Thread
House Wires
Fixture Wires
Hot
I
J
K
B
D
A
E
C
F
H
G
L
N
M
