Seite 1/2
Gigabit Unmanaged PoE Switch
Quick Start Guide
UD16266B
Grounding Terminal
The grounding terminal is used to connect to the ground cable to
protect the switch from lightning.
Power Supply
Use the aached power cord to connect the switch to socket.
Security Hole
Use the steel cable lock (oponal) to lock the switch.
Gigabit Hi-PoE Port
Used for other Hi-PoE PTZ cameras connecon, and the max. power
is 90 W.
Gigabit PoE Port
Used for other PoE devices connecon via network cables.
Gigabit RJ45 Port
Used for devices connecon via network cables.
Gigabit SFP Fiber Opcal Port
Used for other devices connecon via opcal fiber when plugged into
with an opcal module.
DIP Switch
Three modes are supported:
• Extend: The last 2 PoE ports of DS-3E0505/10HP and the last 4 of
DS-3E0520/28HP support network transmission of up to 300 metres.
• Isolaon: Data transmission of each port is Isolated from each other
to Improve network security.
• PoE Watchdog: Auto-detect and restart cameras that do not respond.
DS-3E0505HP
DS-3E0510HP
DS-3E0505HP
All figures in this guide are used for illustraon purpose only. The actual
product may differ.
Device Connecon
Connect your devices according to your actual networking requirements.
(Take the DS-3E0510HP series switch as an example.)
2
3
1
4
5 6
DS-3E0510HP
The front panel of DS-3E0528HP switch is similar to that of DS-3E0520HP, with
differences on 20 gigabit PoE ports, 28 LINK/ACT, 24 PoE indicators and fiber
opcal ports are port 27 & 28.
Switch
Quick Start Guide
Power adapter
Item
Model
Power cord
L-shaped bracket
Screw
DS-3E0505/10HP
× 1
× 1
× 1
× 1
—
—
DS-3E0520/28HP
× 1
× 1
× 1
× 1
× 4
—
Applicable Models
This manual is applicable to DS-3E05XXHP series Gigabit unmanaged PoE switch.
Symbol Convenons
The symbols that may be found in this document are defined as follows.
During the installaon and ulizaon of the device, please strictly conform to electrical
safety rules in different naons and regions.
Use the aached power adaptor only and not to change the adaptor randomly. Please
refer to specificaon table for specific requirements of power adaptor.
Never aempt to disassemble the device yourself. (We shall not assume any
responsibility for problems caused by unauthorized repair or maintenance.)
The device must be installed in machine room only, and only maintenance staff or
qualified person should access to the device.
Do not touch the upper cover area of the device that may be overheated.
Power must be shut down during cable connecon, device installaon and
dismantlement.
You shall acknowledge that the use of the device with Internet access might be under
network security risks, please strengthen protecon for your personal informaon and
data security. If you find the device might be under network security risks, please contact
with us.
Proper configuraon of all passports and other security sengs is the responsibility of
the installer, and you shall keep user name and passports properly.
Please keep all original packing materials properly. If the product does not work properly,
pack the switch in its original packing materials for shipping. We shall not assume any
responsibility for damages caused by improper packing materials during shipping.
Ensure that your devices powered via the PoE port have their shells protected and
fire-proofed, because the switches are not compliant with the Limited Power Source
(LPS) standard.
This is a class A product and may cause radio interference in which case the user may be
required to take adequate measures.
Indicates a hazard with a high level of risk, which if
not avoided, will result in death or serious injury.
Symbol Descripon
Provides addional informaon to emphasize or
supplement important points of the main text.
Indicates a potenally hazardous situaon, which if not
avoided, could result in equipment damage, data loss,
performance degradaon, or unexpected results.
•
•
•
•
•
•
•
•
•
•
•
Packing List
Interfaces
Front Panel
Rear Panel
6 KV Surge Protecon
802.3bt Hi-PoE
Wireless AP
NVR
IP Camera
PoE Watchdog
PoE
VoIP Phone
Up to 100 meters
Up to 300 meters
802.3bt
Hi-PoE PTZ
Control Center
Internet
Data
Power+Data(PoE)
Opcal Fiber
PoEHi-PoE UPLINK
PoE-MAX
Indicator
PWR
Indicator
Gigabit PoE Ports
Gigabit
Hi-PoE
Port
Gigabit
RJ45 Port
LINK/ACT
Indicator (Port 10 )
PoEHi-PoE UPLINK
PoE-MAX
Indicator
PWR Indicator
Gigabit PoE Ports
Gigabit
Hi-PoE Port
Gigabit
RJ45
Port
Gigabit SFP
Fiber Opcal
Ports (Port 10)
DS-3E0520HP
LINK/ACT
Indicator
PoE
Indicator
PoE-MAX
Indicator
PWR
Indicator
ON
1 2 3
DIP
Switch
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19 20
Gigabit
PoE
Ports
Gigabit
Hi-PoE
Ports
Gigabit
RJ45
Ports
Gigabit SFP Fiber
Opcal Ports
(Port 19/10)
K
ON
1 2 3
DIP Switch
Grounding
Terminal
Power
Supply
PWR
DC 48V
Security Hole
K
ON
1 2 3
DIP Switch
Grounding
Terminal
Power
Supply
PWR
DC 54V
Security Hole
K
PWR
AC 100-240V, 50/60Hz
Grounding
Terminal
Power
Supply
Security
Hole
DS-3E0520/28HP
DS-3E0505HP series switches are not equipped with the fiber opcal port, so they cannot use the opcal fiber to transmit data.
