Seite 1/19
INSTRUCTION MANUAL
FRANÇAIS p. 17
ESPAÑOL pg. 9
Green Rotary Laser Level
ENGLISH
• 1,150' (350 m) RANGE
(WITH DETECTOR)
IP66
93RLS
2
Klein Tools 93RLS is a self-leveling laser with an operating range of 1150' (350 m) (with
detector), designed for all leveling projects. Also comes with a plumb laser line.
ROTARY LASER LEVEL:
• Operating Altitude: 6562 ft. (2000 m)
• Relative Humidity: <80% non-condensing
• Operating Temp: 20°F to 120°F (-10°C to 50°C)
• Storage Temp: -5°F to 140°F (-20°C to 60°C)
• Lasers: 510-530 nm , ≤ 5 mW Class 3R, tp ≤ 250ms
• Range: 1150' (350 m)with detector
• Accuracy: +/- 1 mm per 10 m
• Battery Type: Internal Li-Ion, 3.6V 10000 mAH (36.00Wh)
• Battery Life: 30 Hours
• Charging Requirements: Max 5V DC, Max 2.0 A
• Dimensions: 31.93" × 15.88" × 8.57" (81 × 40 × 22 cm)
• Weight: 76 oz. (2.15 kg)
• Calibration: Calibrated for accuracy at factory
• Standards: EN61326-1:2013, IEC60825-1:2014, CE, UKCA, ROHS, REACH,
DOE/CEC, NRCan.
Complies with 21 CFR 1040.10 and 1040.11 except for conformance with IEC
60825-1 Ed. 3, as described in Laser Notice No. 56, dated May 8, 2019.
• Drop Protection: 3.3' (1 m)
• Ingress Protection: IP66 Dust & Water Resistant
DETECTOR:
• Operating Altitude: 6562 ft. (2000 m)
• Relative Humidity: <80% non-condensing
• Operating Temp: 20°F to 120°F (-10°C to 50°C)
• Storage Temp: -5°F to 140°F (-20°C to 60°C)
• Battery Type: 2× AA Alkaline
• Dimensions: 5.62" × 2.78" × 1.1" (143 × 71 × 28 mm)
• Weight: 6.24 oz. (177 g)
• Drop Protection: 3.3' (1 m)
• Ingress Protection: IP54
Specifications subject to change.
FCC AND IC COMPLIANCE
See this product’s page at for FCC compliance information. Canada www.kleintools.com
ICES-003 (B) / NMB-003 (B)
ENGLISH
4
12
1.
Power On/Off Button
5.
Bump Reset Mode Indicators
9.
Excessive Tilt Indicator
2.
Rotation Speed Button
6.
USB-C Charge-In Port
10.
Battery Charge Indicator LEDs
3.
Rotation Speed Indicators
7.
Rotary Plane Aperture
11.
5/8-11 Tripod Mounts
4.
"Bump Reset" Button
8.
Plumb Spot Aperture
12.
USB-C Charging Cable
FEATURE DETAILS - LEVEL (93RLS)
FEATURE DETAILS - GRADING ROD (93RLSGR)
SYMBOLS ON INSTRUMENT - LEVEL (93RLS)
Rotation Speed
Out-Of-Level
Indicator
IP66
Ingress Protection IP66 Rating -
Dust & Water Resistant
Bump Reset
Hazardous laser
radiation
Laser Aperture
Warning or
Caution
Warning – Risk of
electric shock
Read instructions
LASER
3R
Laser Class 3R
Avoid direct eye
exposure
WEEE –
Electronics disposal
Conformité Européenne: Conforms with
European Economic Area directives
UKCA - United Kingdom
Conformity Assessment
ENGLISH
11
6
9
4
3
10
7
2
8
5
1
13.
Rail
14.
Measurement Scales
15.
Spring-Loaded Button
15
13
14
