Seite 1/2
MP 110 - MP 111
MP 115 - MP 112
Manometer
DATA SHEET
Parameter Models Measuring units Accuracy Measuring range Resolution**
Pressure
MP 110 Pa, mmH
2
O, inWg, daPa ±0.5% of reading ±2 Pa From -1000 to +1000 Pa 1 Pa
MP 111
kPa, mmH
2
O, inWg, mbar,
mmHg, daPa
±0.5% of reading ±2 mmH
2
O From -1000 to +1000 mmH
2
O
From 0 to ±200 mmH
2
O: 0.1 mmH
2
O
Beyond: 1 mmH
2
O
MP 115
kPa, inWg, mbar, mmHg,
PSI
±0.5% of reading ±0.5 mbar From -500 to +500 mbar 0.1 mbar
MP 112
kPa, inWg, mbar, mmHg,
PSI, bar
±0.5% of reading ±2 mbar From -2000 to +2000 mbar 1 mbar
Features
• Pressure measurement
• Selection of units
• Manual autozero
• Hold function
• Display of minimum and maximum
values
• Congurable Auto shut-off
• Backlight
Technical specications
Selection of unitsEasy to use
Manual autozeroHold-min-max functions
Supplied with
CALIBRATION
certicate*
*Except class 110 S which is supplied with adjustment certicate.
**All the accuracies indicated in this technical datasheet were stated in laboratory conditions, and can be guaranteed for measurements carried out in the same conditions, or carried out with calibration compensation.
Measuring element Piezoresistive sensor
Tolerated
overpressure
MP 110: 250 mbar / MP 111: 700 mbar
MP 115: 1.4 bar / MP 112: 3 bar
Connector
MP 110 / 111: Ø 6.2 mm barbed connectors made of nickelled brass
MP 115 / 112: Ø 4.6 mm barbed connectors made of nickelled brass
Display
4 lines, LCD technology. Dimensions 50 x 36 mm.
2 lines of 5 digits with 7 segments (value)
2 lines of 5 digits with 16 segments (unit)
Housing ABS, protection IP54
Keypad 5 keys
European
directives
2014/30/EU EMC; 2014/35/EU Low Voltage;
2011/65/EU RoHS II; 2012/19/EU WEEE
Power supply 4 batteries AAA LR03 1.5 V
Battery life 180 hours
Ambience Neutral gas
Conditions of use
(°C, %RH, m)
From 0 to +50 °C. In non condensing conditions.
From 0 to 2000 m.
Storage
temperature
From -20 to +80 °C
Auto shut-off Adjustable from 0 to 120 min
Weight 220 g
General features Dimensions (in mm)
Kit content
Accessories
FT_EN – MP120 – 21/07/23 – Non-contractual document – We reserve the right to modify the characteristics of our products without prior notice.
Operating principle
Piezoresistive sensor
The pressure deforms the silicon layer. This layer deformation generates
a voltage at its terminates.
This voltage is proportional to the pressure applied.
Voltage
Vacuum
Silicon layer
Pressure
71.5
147.9
34.2
6.2
8.5
22
sauermanngroup.com
Designation
Sales
reference
Description
MP 110 24615
Manometer with 2 x 1 m of silicon
tube Ø 4 x 7 mm, stainless steel tip
Ø 6 x 100 mm, calibration certi-
cate and soft transport case
MP 110 S 24712
Manometer with 2 x 1 m of silicon
tube Ø 4 x 7 mm, stainless steel tip
Ø 6 x 100 mm, adjustment certi-
cate and soft transport case
MP 111 24616
Manometer with 2 x 1 m of silicon
tube Ø 4 x 7 mm, stainless steel tip
Ø 6 x 100 mm, calibration certi-
cate and soft transport case
MP 111 S 24713
Manometer with 2 x 1 m of silicon
tube Ø 4 x 7 mm, stainless steel tip
Ø 6 x 100 mm, adjustment certi-
cate and soft transport case
MP 112 24618
Manometer with 2 x 1 m of crystal
tube Ø 4 x 6 mm, calibration certif-
icate and soft transport case
MP 112 S 24721
Manometer with 2 x 1 m of crystal
tube Ø 4 x 6 mm, adjustment
certicate and soft transport case
MP 115 24617
Manometer with 2 x 1 m of crystal
tube Ø 4 x 6 mm, calibration certif-
icate and soft transport case
MP 115 S 24720
Manometer with 2 x 1 m of crystal
tube Ø 4 x 6 mm, adjustment
certicate and soft transport case
Designation
Sales
reference
Description
CQ 15 24633 Magnetic protective housing
J.T.C 11922
Straight junctions in T
for Ø 5 x 8 mm tube
J.T.Y 11923
Straight junctions in Y
for Ø 5 x 8 mm tube
Pitot Tubes -
Different lengths, Ø 3/6 or 8mm, bent or
straight. See related data sheet.
MT 51 24636 ABS transport case
ST 110 24635 Soft transport case
Calibration certicate: A calibration is a
comparison of the values of the instrument with
those of a standard to determine a measurement
error with an associated calibration uncertainty. A
calibration certicate guarantees the traceability of
measurements to national standards.
Adjustment certicate: An adjustment certicate is
a document that ensures the conformity of the device
with the tolerances of the data sheet. It ensures that
the device has followed the manufacturing process.
Certicates
Maintenance
We carry out calibration, adjustment and maintenance of your
instruments to guarantee a constant level of quality of your
measurements.
As part of Quality Assurance Standards, we recommend you to carry out
a yearly checking.
