Seite 1/2
Si-33
Piston pump
Sauermann
®
part #: SI33CE01UN23
Max ow rate
The high capacity Si-33 (30l/h) is suitable for air-conditioning units from
20 kW up to 30 kW. The piston pump inside the Si-33 is specically designed for
removing condensates from air conditioning systems, whatever the environment.
Kit content
Benets
• Piston pump
• Clear PVC tube Ø int. 6 mm – L: 1 m, tted
with a ‘‘Drain Safe Device’’ pre-mounted
• Anti-vibration mounting bracket
• 1.5 m lockable plug-in power cable:
2 power wires, 2 safety switch wires
• 6 tie wraps, 2.5 x 100 mm
• Detection unit (SI2958, 1.5 m cable)
• Detection unit installation kit:
- rubber elbow 90° Ø int.15 x L 60 mm,
- vent tube Ø int. 4 x L 75 mm,
- mounting rail, adhesive
DATA SHEET
Patented technology
• High performance: pump suitable for
air-conditioning units from 20 kW up to 30 kW.
• High resistance to pollution created by general
environment. Capable of discharging small
particles.
• Proven Reliability.
• The Drain Safe Device retains prime and
prolongs the pump life.
Easy to install
• Compact design.
• New mounting bracket: allows the pump to be wall
mounted or hung from ceilings and pipework.
• Lockable plug-in power cord to avoid unintended
disconnection.
Energy saving
• Improved performance and high ow rate reduce
operation time and energy consumption.
Low sound level
• Low sound level in operation: 34 dBA independently
tested.
• Mounting bracket specically designed to reduce
vibration transmission to the wall / panel or pipework.
For use with any air-conditioning units,
from 20 kW up to 30 kW:
Name #Part
Clear PVC hose
Ø int. 6 mm (1/4’’)
ACC00909: 5 m
ACC00910: 50 m
6 Self-sealing
ttings for hose
Ø int. 6 mm (1/4’’)
ACC00919
Tecnical specications
Accessories
Applications
Actual ow rates (l/h)
sauermanngroup.com
SI33CE01UN23_EN - 27/06/2018 – Non-contractual document. We reserve the right to modify the characteristics on our products without prior notice.
Max. ow rate 30 l/h
Max. suction head 3.3 m
Max. discharge head 13 m (ow rate = 8 l/h)
Max pressure 18 m (ow rate = 0 l/h)
Sound level at 1m
EN ISO 3744 (Measured at LNE lab, pump opera-
ting with water, out of application)
≤ 34 dBA
Sound level in application at 1m:
(Measured in Sauermann acoustic lab, pump
operating with water)
≤ 36 dBA
Mains supply 230 V~ 50/60 Hz - 21 W
Insulation class
(double insulation)
Detection levels ON: 16 mm; OFF: 11 mm; Safety: 19 mm
Safety switch NC 8 A resistive – 250 V
Thermal protection (overheating) 115 °C (auto-reset)
Max. condensate temperature 35 °C
Operating conditions 50 %: 3 s ON – 3 s OFF
Protection IP20
Safety standards CE et EAC
RoHS directive Compliant
WEEE directive Compliant
Packaging L 135 x W 135 x H 90 mm
Weight (including box) 0.48 kg
Total tube length using
(Ø int. 6 mm, 1/4’’ ) (C)
Suction head
(A)
Discharge
head (B)
5 m 10 m 20 m 30 m
0 m
0 m 30 27 26 25
2 m 26 24 23 22
4 m 22 21 20 19
6 m 18 17 16
8 m 15 14 13
10 m 12 11 10
12 m 8 7
2 m
0 m 21 20 19 18
2 m 17 16 15 14
4 m 14 13 12 11
6 m 10 9 8
8 m 7 6 5
Total tube length using
(Ø int. 6 mm, 1/4’’ ) (C)
Suction head
(A)
Discharge
head (B)
5 m 10 m 20 m 30 m
• Wall mounted
• Ceiling suspended
• Ducted
• Fan-coils
1 m
0 m 24 23 22 21
2 m 20 19 18 17
4 m 17 21 15 14
6 m 16 12 11
8 m 13 9 8
10 m 10 6 5
3 m
0 m 18 17 16 15
2 m 15 14 13 12
4 m 10 9 8
6 m 6 5 4
Discharge head (m)
Flow rate(l/h)
