Seite 1/2

Hydrogon D120 ARGB

High performance CPU cooler

I J

Contents

www.silverstonetek.com

电机组件

金属结构件

塑胶结构件

线缆/ 连接器

介质/其它

包装材料

辅助材

Warranty Information

This product has a limited 1 year warranty in North America and Australia.

For information on warranty periods in other regions, please contact your reseller or SilverStone authorized

distributor.

本产品自购买之日起，于中国地区（不包含澳门，香港特别行政区）享有一年有限责任保固（部分产品为二年，

三年或五年）。详细保固年限请参照官方网站 www.silverstonetek.com.cn 公布之产品型号为依据。

1. Product component defects or damages resulted from defective production is covered under warranty.

Defects or damages with the following conditions will be fixed or replaced under SilverStone Technology’s

jurisdiction.

a) Usage in accordance with instructions provided in this manual, with no misuse, overuse, or other

inappropriate actions.

b) Damage not caused by natural disaster (thunder, fire, earthquake, flood, salt, wind, insect, animals, etc…)

c) Product is not disassembled, modified, or fixed. Components not disassembled or replaced.

d) Warranty mark/stickers are not removed or broken.

Loss or damages resulted from conditions other than ones listed above are not covered under warranty.

2. Under warranty, SilverStone Technology’s maximum liability is limited to the current market value for the

product (depreciated value, excluding shipping, handling, and other fees). SilverStone Technology is not

responsible for other damages or loss associated with the use of product.

3. Under warranty, SilverStone Technology is obligated to repair or replace its defective products. Under no

circumstances will SilverStone Technology be liable for damages in connection with the sale, purchase,

or use including but not limited to loss of data, loss of business, loss of profits, loss of use of the product or

incidental or consequential damage whether or not foreseeable and whether or not based on breach of

warranty, contract or negligence, even if SilverStone Technology has been advised of the possibility of

such damages.

4. Warranty covers only the original purchaser through authorized SilverStone distributors and resellers and

is not transferable to a second hand purchaser.

5. You must provide sales receipt or invoice with clear indication of purchase date to determine warranty

eligibility.

6. If a problem develops during the warranty period, please contact your retailer/reseller/SilverStone

authorized distributors or SilverStone

. http://www.silverstonetek.com

Please note that: (i) You must provide proof of original purchase of the product by a dated itemized receipt;

(ii) You shall bear the cost of shipping (or otherwise transporting) the product to SilverStone authorized

distributors. SilverStone authorized distributors will bear the cost of shipping (or otherwise transporting) the

product back to you after completing the warranty service; (iii) Before you send the product, you must be

issued a Return Merchandise Authorization (“RMA”) number from SilverStone. Updated warranty

information will be posted on SilverStone’s official website.

Please visit for the latest updates.http://www.silverstonetek.com

Warranty terms & conditions

Additional info & contacts

For North America (usasupport@silverstonetek.com)

SilverStone Technology in North America may repair or replace defective product with refurbished product that is not

new but has been functionally tested.

Replacement product will be warranted for remainder of the warranty period or thirty days, whichever is longer.

All products should be sent back to the place of purchase if it is within 30 days of purchase, after 30 days,

customers need to initiate RMA procedure with SilverStone Technology in USA by first downloading the “USA

RMA form for end-users” form from the below link and follow its instructions.

http://silverstonetek.com/contactus.php

For Australia only (support@silverstonetek.com)

Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.

You are entitled to a replacement or refund for a major failure and for compensation for any other reasonably

foreseeable loss or damage.

You are also entitled to have the goods repaired or replaced if the goods fail to be of acceptable quality and the failure

does not amount to a major failure.

Please refer to above “Warranty terms & conditions” for further warranty details.

SilverStone Technology Co., Ltd. 12F No. 168 Jiankang Rd., Zhonghe Dist., New Taipei City 235 Taiwan R.O.C.

+ 886-2-8228-1238 (standard international call charges apply)

For Europe (support.eu@silverstonetek.de)

For China (support@silverstonetek.com.cn)

For all other regions (support@silverstonetek.com)

This device complies with Part 15 of the FCC Rules.

Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that may cause undesired operation.

NO.G11241900

○：表示该有毒有害物质在该部件

所有均质材料中的含量均在GB

/T 26572 规定的限量要求以下。

本表格依据SJ/T 11364的规定编制

×：表示该有毒有害物质至少在该部

件的某一均质材料中的含量超出

GB/T 26572 规定的限量要求。

Intel LGA 115x / 1200/ 1366

Intel LGA 2011 / 2066

*Please use the AMD backplate comes with mainboard

Intel

LGA 2011 / 2066

AMD CPU

LGA 115x/1200

LGA 1366

LGA 775

Intel

AMD

J M

Mainboard CPU_FAN headerMainboard ARGB header

GND

D +5VD

Assembly

Please confirm the connector, the definition and direction of your

pin header when connecting cables

Ensure ARGB controller / motherboard has same +5V pin definition

as HYD120-ARGB

Bitte bestätigen Sie den Stecker, die Definition und Richtung Ihrer

Stiftleiste beim Anschließen der Kabel

Stellen Sie sicher, dass ARGB-Controller / -Motherboard dieselbe

+5-V-Pinbelegung hat wie HYD120-ARGB

Veuillez confirmer le connecteur, la définition et la direction de

votre en-tête de broche lors de la connexion des câbles

Assurez-vous que le contrôleur ARGB/la carte mère a la même

définition de broches +5 V que HYD120-ARGB

Confirme el conector, la definición y la dirección de su encabezado

de pin al conectar los cables

Asegúrese de que el controlador / placa base ARGB tiene la

misma configuración de pines +5V que el HYD120-ARGB

Confermare il connettore, la definizione e la direzione

dell'intestazione del pin quando si collegano i cavi

Assicurarsi che il controller/la scheda madre ARGB abbia la stessa

definizione di pin a +5 V dell'iHYD120-ARGB

Пожалуйста, подтвердите разъем, определение и направление

вашего штыревого разъема при подключении кабелей

Убедитесь, что ARGB-контроллер/материнская плата имеет так

ое же определение контактов + 5В, что и HYD120-ARGB

โปรดยืนยันการเชื่อมต่อคาจากัดความและทิศทางของส่วนหัวของขาเมื่อต่อ

สายเคเบิล

ตรวจดูให้แน่ใจว่า คอนโทรลเลอร์ / เมนบอร์ด ARGB มีข้อกาหนดพิน +5V

เดียวกับ HYD120-ARGB

เชื่อมต่อขั้วต่อพัดลมเข้ากับขั้วต่อเมนบอร์ดที่เกี่ยวข้อง

ケーブルを接続するときは、コネクタ、ピンヘッダーの定義と方

向を確認してください

+5Vピン配列に関し、ARGBコントローラ/ マザーボードが

HYD120-ARGBと同一であることを確認してください

케이블을 연결할 때 커넥터, 핀 헤더의 정의 및 방향을 확인하십시오

HYD120-ARGB처럼 ARGB 컨트롤러 / 마더보드가 동일한 +5V 핀

배열을 지원하는지 확인하여 주십시오

在安裝傳輸線時，請確認連接頭定義、方向

确保ARGB控制器/主板的+ 5V pin定义与相同HYD120-ARGB

在安装传输线时，请确认连接头定义、方向

確保ARGB控制器/主板的+ 5V pin定義與相同HYD120-ARGB

Please use the AMD backplate comes with mainboard

Bitte verwenden Sie die mit dem Motherboard gelieferte

AMD-Backplate

Veuillez utiliser la plaque arrière AMD fournie avec la carte mère

Utilice la placa posterior AMD que viene con la placa base

Utilizzare la piastra posteriore AMD fornita con la scheda madre

Используйте заднюю панель AMD, поставляемую с материнско

й платой

โปรดใช้แผ่นรองหลังของ AMD ที่มาพร้อมกับเมนบอร์ด

マザーボードに付属のAMDバックプレートを使用してください

마더 보드와 함께 제공되는 AMD 백 플레이트를 사용하십시오

请使用您主机板上的AMD背板进行安装

請使用您主機板上的AMD背板進行安裝

Produktspezifikationen

Marke:	SilverStone
Kategorie:	PC Kühlventilator
Modell:	Hydrogon D120 ARGB
Breite:	125 mm
Tiefe:	112 mm
Gewicht:	885 g
Produktfarbe:	Black, Metallic, White
Höhe:	153 mm
Material:	Kupfer
Warentarifnummer (HS):	84733080
Typ:	Luftkühlung
Menge pro Packung:	1 Stück(e)
Nennstrom:	0.21 A
Geräuschpegel:	30.5 Sone
Empfohlene Platzierung:	Computergehäuse
Kompatible Produkte:	Intel LGA 2066/2011/1200/115x/1366/775\nAMD Socket AM4/AM3/AM2/FM2/FM1
Lüfterdurchmesser:	120 mm
Ventilator-Anschluss:	4-polig
Unterstützte Prozessorsteckplätze:	LGA 1150 (Socket H3), LGA 1151 (Socket H4), LGA 1155 (Socket H2), LGA 1156 (Socket H), LGA 1200 (Socket H5), LGA 1366 (Socket B), LGA 2011 (Socket R), LGA 2066, Socket 755, Socket AM2, Socket AM3, Socket AM4, Socket FM1, Socket FM2
Maximum Luftdruck:	1.98 mmH2O
Unterstützung der Pulsweitenmodulation:	Ja
Abmessungen Gebläse (B x T x H):	120 x 120 x 25 mm
Rotationsgeschwindigkeit (min.):	0 RPM
Rotationsgeschwindigkeit (max.):	1850 RPM
Lagertyp:	Hydraulisch
Nennspannung:	12 V
Lamellenmaterial:	Aluminium
