T415.50X

T420.50X

Series

PORTSMOUTH

™

IN WALL PRESSURE BALANCING

BATH AND SHOWER TRIM KIT

To assure proper positioning in relation to wall,

note roughing-in dimensions.

ROUGHING-IN DIMENSIONS

Certified to comply with ANSI A112.18.1

Installation

Instructions

Tubing Cutter

5/64"

Hex Wrench

Recommened Tools

Adjustable Wrench

Channel Locks

Flat Blade Screwdriver

Plumbers' Putty or Caulking

Phillips Screwdriver

Thank you for selecting American-Standard...

the benchmark of fine quality for over 100 years.

To ensure that your installation proceeds smoothly--

please read these instructions carefully before

you begin.

1-5/8" TO 3"

(41mm TO 76mm)

FINISHED WALL

4" (102 mm)

BOTTOM OF TUB

74" FOR HEAD CLEARANCE

(188 cm)

18" OPTIONAL

(45,7 cm)

5-1/8" REF.

(130 mm) REF.

1/2" NPT

(12,7 mm) NPT

7-5/8"

(195 mm)

7-13/16"

(198 mm)

OPTIONAL TO FINISHED FLOOR

USUALLY BETWEEN 65'' AND 78''

TOP OF TUB RIM

SHR

TUB

"SEE ILLUSTRATION"

T415T420

H

C

216mm

(8-1/2")

REF.

125mm

(4-7/8")

REF.

1/2" COPPER

1-1/2" REF.

(38mm) REF.

INLETS 1/2" NPT

ESCUTCHEON T415

OUTLETS

1/2" NPT

3-3/8"

3-3/8"

6-1/2"

(165 mm)

ESCUTCHEON T420

7-5/8" DIA.

(195 mm)

THREADED INLETS (STOPS)

INLETS

1/2" NPT

5-7/8"

OUTLETS

1/2" NPT

3-3/8"

THREADED INLETS

SHR. 1/2" NOM.

COPPER SWEAT

TUB 1/2" NOM.

COPPER SWEAT

4-1/16"

5-7/8"

INLETS

4-1/16"

4-1/16"

INLETS

1/2" NOM.

COPPER

SWEAT

SHR. 1/2" NOM.

COPPER SWEAT

TUB 1/2" NOM.

COPPER SWEAT

2"

SWEAT

INLETS

SWEAT

INLETS (STOPS)

INLETS

1/2" NOM.

COPPER

SWEAT

C

o

ld

Ho

t

M965028 REV.1.7 (12/14)

Teflon

Tape
