WARNINGS
To ensure safe operation and service of the thermometer, follow these
instructions. Failure to observe these warnings can result in severe injury
or death.
• Read the instructions to ensure safe operation.
• Thermometer is NOT insulated. Avoid contact with areas where
energized conductive elements may be present. Shut off power to the
area before starting measurements.
• Thermometer is NOT intended for use on people or animals.
• Always wear approved eye protection and any other personal
protective equipment (PPE) as required.
GENERAL SPECIFICATIONS
Klein Tools ET10 is a digital thermometer with a magnetic base that easily
attaches to air vents for HVAC air temperature readings, and takes ambient and
direct-contact readings in both Fahrenheit (°F) and Celsius (°C) scales.
• Measurement Range: -40 to 572°F (-40 to 300°C)
• Resolution: 0.1°F/C
• Accuracy:
• Temperature stability: 3 seconds
• Batteries: 2x LR44 Button Cell
• Operating Altitude: 6562 ft. (2000 m)
• Operating Temp: ° ° ° °32 to 122 F (0 to 50 C)
• Storage Temp: ° ° ° °-4 to 140 F (-20 to 60 C)
• Relative Humidity: Operating: 10% to 90% non-condensing
Storage: <80% non-condensing
• Dimensions: 6.50" x 1.08" x 0.96" (165 x 27 x 24 mm)
• Weight: 1.5 oz. (42.5 g) including batteries
• Pollution degree: 2
• Drop Protection: 9.8 ft. (3 m)
• Stainless steel probe: Complies with FDA/GRAS
(Generally Recognized As Safe) requirements.
NOTE: Although the thermometer can measure up to 572°F (300°C), the plastic
body and sheath are rated only to 160°F (71°C). expose thermometer DO NOT
to temperatures above 160°F (71°C); the stainless steel probe can only
withstand temperatures above 160°F (71°C), and only for a short time.
Specifications subject to change.
ENGLISH
FEATURE DETAILS
(
FIG. 1
)
Range Accurate To
-40 to -4°F (-40 to -20°C) +/-3.6°F (+/- 2°C)
-3 to 302°F (-19 to 150°C) +/-2.7°F (+/- 1.5°C)
Above 303°F (150°C) +/- 2%
FRONT OF UNIT
1.
3" Stainless Steel Probe
5.
MAX/MIN/AVG Button
2.
Protective Sheath/Handle
6.
°F/°C Select Button
3.
Backlit LCD Screen
7.
HOLD Button
4.
Power Button
BACK OF UNIT
8.
Pocket Clip
10.
Magnet (inside housing)
9.
Battery Compartment (inside base of pocket clip)
LCD DISPLAY
A.
Measurement
E.
AVG Icon
B.
HOLD Icon
F.
Battery Strength Indicator
C.
MAX Icon
G.
°F/°C Icon
D.
MIN Icon
H.
Auto Power-Off Icon
FIG. 1
FUNCTION BUTTONS
ON/OFF BUTTON
4
Press the Power Button to power on and off the thermometer.
AUTO POWER-OFF
Auto Power-Off will automatically turn off the meter after 15 minutes of
inactivity. When powered on, Auto Power-Off is enabled by default. To
disable the Auto Power-Off function, press and hold the MAX/MIN/AVG
Button
5
while powering on. The Auto Power-Off icon
H
will disappear
from the display. After powering off, the Power-Off function will be Auto
enabled when powered on again; repeat this process to disable again.
°F/°C SELECT BUTTON
6
The thermometer's default measurement scale upon power-up is
Fahrenheit (°F). Press the °F/°C button o toggle between Fahrenheit (°F) t
and Celsius (°C).
HOLD BUTTON
7
Press the HOLD button to lock the current reading on the display. Press
again to return to active measurement mode.
MAX/MIN/AVG BUTTON
5
The MAX/MIN/AVG button toggles between (in order) Max, Min, Average
(AVG), and Data Point modes. Data is refreshed with every entry.
• MAX: Displays the highest temperature measured.
• MIN: Displays the lowest temperature measured.
• AVG: Displays an average of the temperature while scanning.
• Data Point mode displays the number of data points collected.
To return to normal measuring mode, press the MAX/MIN/AVG button for
more than two seconds.
BACKLIGHT
To activate the Backlight, press the MAX/MIN/AVG button
5
and the °F/°C
button
6
simultaneously. Backlight will automativally deactivate after
approx. 30 seconds; repeat this process to reactivate.
OPERATING INSTRUCTIONS
1. Power on the thermometer and select range, as °F or °C
described in section.FUNCTION BUTTONS
2. The thermometer will begin measuring temperature immediately
upon power-up. Ambient environmental temperatures may be
measured with the protective sheath in place. Remove sheath
for direct-contact temperature measurements.
NOTE:
The sheath
can be attached to the back of the thermometer body to act as a
handle/extension, as shown in FEATURE DETAILS.
CAUTION: To avoid accidental injury, always keep the
protective sheath secured over the probe when not taking
direct-contact measurements.
NOTE: OR The warning " " will appear on the LCD display if the
attempted measurement is outside of the thermometer's range.
3. Refer to section to use other features such FUNCTION BUTTONS
as HOLD, MAX, MIN and AVG (Average).
CLEANING
Be sure thermometer is turned off and wipe with a clean, dry
lint-free cloth.
Do not use abrasive cleaners or solvents.
STORAGE
Remove the batteries when the meter is not in use for a prolonged
period of time. Do not expose to high temperatures or humidity.
After a period of storage in extreme conditions exceeding the
limits mentioned in the General Specifications section, allow the
thermometer to return to normal operating conditions before using.
WARRANTY
www.kleintools.com/warranty
DISPOSAL / RECYCLE
Do not place equipment and its accessories in the trash.
Items must be properly disposed of in accordance with local
regulations. Please see www.epa.gov www.erecycle.org or
for additional information.
CUSTOMER SERVICE
KLEIN TOOLS, INC.
450 Bond Street
Lincolnshire, IL 60069
1-877-775-5346
www.kleintools.com
MAINTENANCE
BATTERY REPLACEMENT
When the Low Battery indicator is displayed on the LCD, the
batteries must be replaced.
1. Rotate the pocket clip
8
approx. 90 degrees counterclockwise
as shown to expose the battery compartment (FIG. 2).
2. Remove and recycle the two spent LR44 batteries (FIG. 3).
3. Install two new LR44 batteries, with the positive (+) side facing up
as shown (FIG. 3).
4. Replace pocket clip and rotate approx. 90 degrees clockwise to
lock into place (FIG. 2).
NOTE: There are no user-serviceable parts inside thermometer.
B F
D
C
E
H
A
G
8
10
3
5
6
4
1
2
Warranty / Garantía / Garantie :
www.kleintools.com/warranty
WARNINGS and instructions: See inside.
ADVERTENCIAS
y instrucciones: Ver en interior.
ADVERTISSEMENTS et instructions : Voir à l’intérieur.
Made in China
Hecho en China
Fabriqué en Chine
1330508 Rev 08/17 A
KLEIN TOOLS, INC
Chicago, IL USA
© 2017
• User-selectable readings in Fahrenheit (-40°F to 572°F) and
Celsius (-40°C to 300°C).
• Magnet inside base of probe to easily attach to air vents for hands-
free measurements.
• Large, dedicated HOLD button to easily lock in measurements.
• Backlit LCD display for easy viewing in low-light environments.
• 15-minute auto power-off to conserve and extend battery life.
• Lecturas seleccionables por el usuario en Fahrenheit (-40°F a 572°F)
y Celsius (-40°C a 300°C).
• Hay un imán en el interior de la base de la sonda para que la
unidad se adhiera fácilmente a las ventilaciones y así poder realizar
mediciones en modo manos libres.
• Botón exclusivo de gran tamaño denominado "HOLD" (RETENER) que
retiene las mediciones con facilidad.
• Pantalla LCD retroiluminada de fácil visualización en lugares
con poca luz.
• Función de apagado automático después de 15minutos de
inactividad que preserva y extiende la vida útil de la batería.
• Lecture réglable par l’utilisateur en Celsius (-40°F à 300°F) et en
Fahrenheit (-40°F à 572°F).
• Aimant à l’intérieur de la base de la sonde servant à xer facilement
le dispositif aux évents a n de permettre une mesure mains-libres.
• Grand bouton HOLD (maintien des données) conçu pour verrouiller
facilement les mesures.
• Écran ACL à rétroéclairage pour faciliter la lecture dans les
endroits sombres.
• Arrêt automatique après 15minutes pour économiser la pile et
augmenter sa durée de vie.
Durability / Durabilidad / Durabilité
Drop Protection / Protección ante caídas /
Protection contre les chutes
9.8 ft.
(3 m)
WARNING: Cancer and reproductive harm – See www.P65Warnings.ca.gov for more information.
Magnetic Pocket ThermometerMagnetic Pocket Thermometer
Termómetro magnético de bolsillo
Thermomètre aimanté de poche
WARNINGS AND INSTRUCTIONS INSIDE - DO NOT DISCARD.
ADVERTENCIAS E INSTRUCCIONES EN EL INTERIOR - NO DESECHAR.
AVERTISSEMENTS ET DIRECTIVES À L'INTÉRIEUR - NE PAS JETER.
Importado por:
KLEIN TOOLS DE MEXICO
S. DE R.L. DE C.V.
AV. Benito Juarez Garcia
No. 75, 77 y 79 No. Int. 9
Col. San Mateo Cuautepec
Tultitlán Estado de México. C.P. 54948
RFC KTM-710310-645
Contenido: 1 pieza
U.S. PATENT PENDING
7
2
x
LR44
Batteries included
Baterías incluidas
Piles comprises
9
FIG. 2 FIG. 3
ET10
